    planer Horizontal And Vertical Milling Machine BXM20 With Planing Grinding Function

    BXM20-1 BXM20-2 standard double column heavy planer-milling machine with planing, milling, grinding function


    Machine Introduction


    BXM20 series standard double column planer-milling machine is a kind of mechatronic product integrating planing,milling and grinding, it is suitable for high-speed steel, carbide cutting tools, and can be used to process all kinds of ferrous metals, nonferrous metals and some non-metallic materials work piece. It can complete plane, milling and grinding processing of flat, slope, side,groove and rack.

    Main technical parameters


    Machine modelBXM20—1BXM20—2BXM20—3BXM20—4
    The center distance of machine bed guidewaymm600700800900
    Width ot beam guidewaymm420500500600
    Max length of workingmm3000,4000,
    6000, 8000,
    10000,12000
    3000,4000,
    6000, 8000,
    10000,12000
    3000,4000,
    6000, 8000,
    10000,12000
    3000,4000,
    6000, 8000,
    10000,12000
    14000
    ,16000
    Max width of workingmm1300,16001600,1800,20001600, 1800, 20002000, 2200
    Max height of workingmm1200,15001200,15001200, 15001500
    Width of worktablemm13001400, 16001400, 16001600, 1800
    Max weight of workingt10-1812-2714-2916-31
    vary as per different specification and model
    Pulling force of worktable rackN40000510005100088000
    Max size of tool barmm40x4050x5050x5060x60
    Moving speed of worktablemm/min30-40000 continuously variable speed range
    Horizontal feed of vertical planner head
    (per travel)
    (mm/pt)0.2-25 continuously variable speed range
    Vertical feed of vertical planer head
    (per travel)
    (mm/pt)0.2-20 continuously variable speed range
    Side planner head feed(per travel)(mm/pt)0.2-6 continuously variable speed range
    Standard configurationOne vertical planer head, one vertical milling head, two side planer heads and one vertical grinding head.(The accessoriescan vary as per the request)
    Elevating speed of beammm/min300
    Power or main motorkw15,22,30, 37,45,55
    Equipping with different motor power according to the different specification and type
    Overall dimension (L*W*H )(L)mm7400750075007500
    (W) mm3000330034004400
    (H)mm3000310031003500
