    Diesel Engine 13.2kw Power Water Well Drilling Rig Crawler Type Hydraulic

    Ask Lasest Price
    Brand Name : JCDRILL
    Model Number : JXY130L
    Certification : ISO 9001:2008
    Price : USD9990
    Payment Terms : T/T
    Supply Ability : 2000 sets per year
    Delivery Time : 5-10 working days
    • Product Details
    • Company Profile

    Diesel Engine 13.2kw Power Water Well Drilling Rig Crawler Type Hydraulic

    JXY130L 130m diesel engine power crawler type hydraulic core sampling drill machine water well drilling rig


    >> Introduction

    XYY-L Series crawler mounted diamond core drilling rig is a kind of core drill rig driven with tungalloy-carbide-tipped bit and diamond-bit, small-diameter. It is mainly suitable for exploration of metal or non-metal solid mineral ore bed. It is widely applied in the field of geology, metallurgy, coal mine, hydrological and engineering drilling. It can also be used in the fields of superficial-zone petroleum and natural gas mining, mine workings ventilation and water discharge tunnel drilling as well as foundation pile construction in large diameter.

    It can be selected according to the underlying different alloy, diamond, compact drill for drilling, etc. Level 3, 2-9 drilling, sandy clay and rock formations, etc.

    Having hydraulic automatic feeding mechanism, improve the drilling efficiency, reduce labor intensity.

    Using the ball card holding mechanism to replace chuck, can implement non-stop down rod, convenient operation, safe and reliable. Hoist with cage, forms the double support structure of the star wheel, can withstand strong shock.

    Four groups of axle box bearing positioning, keep gyrator rigid enough deal with gravel layer, complex geological conditions, such as pebble layer.

    The machine adopts taper clutch of national patent technology, has the big transmission torque, easy to operate, the prominent characteristics of free maintenance.

    >> Characteristic

    >> Specification

    Main machine technical parameterJXY130LJXY180LJXY200L
    Drilling depth(m)130m180m200m
    Drilling hole diameter220220325
    End Hole Diameter(mm)757575
    Drill Rod diameter(mm)42, 6042, 6042, 50, 60
    Drill Angle909090
    Weight engine(kg)288539003990
    Machine Dimension(mm)4200*1980*21504200*1980*21504200*1980*2150
    Power
    Matching engine power(KW)13.213.215
    Spindle
    Speed(r/min)142/285/570130/300/480/730/830/104564/128/287/557
    Stroke(mm)450450450
    Hoist
    Single rope lift force(kg)180021002500
    Single rope lift speed(m/s)0.41-1.640.35-2.230.12-0.95
    Rope diameter(mm)9.39.312.5
    Rope capacity(m)272735
    Drill Mast
    Rated load (Ton)181818
    Effective height(m)6.56.56.5
    Mud Pump
    Flow(L/MIN)160160160
    Max. pressure(Mpa)1.31.31.3
    Back and forth times/min165165165
    Inlet hose dia.(mm)515151
    Outlet hose dia.(mm)323232
    Crawler Chassis20°20°20°
    Crawler Size10Km/h10Km/h10Km/h
    Climbing angle130013001300
    Moving Speed(Km/h)181818
    Hydraulic Landing leg valid height6.56.56.5

    >> Package & Shipment
