3.5inch Square LCD Monitor 320*240 TFT Module With 24bit RGB
Interface
5inch Industrial Capacitive Touch Screen 800*480 Hight Resolution
Tn Tft Lcd Display
1. Specification of 3.5inch square lcd monitor
| Module type | 3.5"TFT |
| Display Mode | TN/Transmissive/Normally white |
| Number of Dots | 320*3(RGB)*240 |
| Viewing Direction | 12 o'clock |
| Module size | 76.9(W)*63.9(H)*3.26(T)mm |
| TFT Active area | 70.08(W)*52.56(H)mm |
| Interface | RGB |
| Luminace | 300cd/m2 |
2. Description of 3.5inch square lcd monitor
ChengHao Display model CH350QV01B is a color active matrix thin
film transistor (TFT) liquid crystal display
(LCD) that uses amorphous silicon TFT as a switching device. This
model is composed of a TFT LCD panel, a driving
IC, a high brightness back-light and FPC.
This TFT LCD has a 3.5 (Horizontal screen) inch diagonally measured
active display area with 320*3(RGB)*240
resolution.
The driver used for this project is the HX8238D or compatible and
can display 16.7M colors by R.G.B. signal
input. The driver is mounted on the glass and the interconnection
via FPC including components to drive the
display module.
In addition, FPC can also be customized according to customer
requirements, such as modifying back-light and
FPC structure, interface definition, etc.
RoHS Compliance & Halogen Free.
3. Drawings of 3.5inch square lcd monitor
4. Our Service
1. Warranty: One year .
2. After-sales Service: For the user questions or machine fault,we
will arrange engineer provide remote-control technical support and
maintenance services for you at any time.
3. Product Quality Assurance: Our products had gone through
authoritative evaluation, approves CE, RoHS certification, and
strict test before shipment.
4. After-sales Service Team: The after-sales service center is
equipped with a professional technical service team with abundant
experience in maintenance and support.
5. Application
6. Products quality assurance
(1)High-quality raw material supplier :
after-sales guarantee and long-term stable supplier, LCD panel and
Driver IC made of A-regulated raw materials.
(2)Other materials:
such as polarizers, backlight film materials, etc. We also use
brand new A-regulated raw materials
(3)Strict quality control:
Through rate up to 98.5%,Customer online defect rate as low as
0.3%.
Inspection is done in FOG==>LCM==>LCM+RTP/CTP==>
production online inspection ==>Q.C inspection==>aging test 4
hours with load in 60 ℃ special room (as option)==>OQC.
A product must pass 5 tests before shipment: incoming inspection,
100% online inspection, QC on-site inspection, aging test and OQC
inspection, etc.
7. FAQ
Q1: Are you manufacturer ?
A: Yes, we are manufacturer.
Q2: How long is your delivery time?
A: Normally 3-5 working days after payment; Special requirement
orders, delivery time is negotiable.
Q3: If the products can't work after receiving it,what should I do?
A: We will replace new items for you at once and then we make the
judgement for the issue.
Q4: Do you accept OEM design?
A: Yes,we do.We can design according to your requirement, MOQ
usually 100-1000.
Q5: Do you accept pay 30% in advance?
A: Yes,we do.We can start to prepare your goods when receive 30%
payment, and send them after get the rest 70% payment.
Q6: What payment terms you accept?
A: We accept Paypal, T/T, Western Union, Wechat, Alipay, in Cash
(RMB or USD).
