    260V 50Hz Biogas Generators Natural Gas 280KW Generator

    Ask Lasest Price
    Brand Name : Starlight
    Model Number : 280 kW
    Price : USD 43000 - 49000 per Set
    Payment Terms : L/C, T/T
    Supply Ability : 100 set per month
    Delivery Time : 30 days
    Certification : ISO9001
    • Product Details
    • Company Profile

    260V 50Hz Biogas Generators Natural Gas 280KW Generator

    260kW Biogas Natural Gas Engine Electricity Generator Natural Gas Generator


    The 280kW natural gas generator set continuous power is 200kW, rated voltage 380V, 50Hz, power factor 0.8.


    Gas Engine

    Deutz V6 natural gas engine are used in for the generator. The gas engine is deeply developed in fuel control systems to improve its electric efficiency, reliability and fuel adaptivity for certain working conditions.The development also give consideration for dynamic responsiveness, fuel economy, reliability and safety.

    Proven gas engine is controlled by imported gas close-loop lean-burn control system which includes high energy ignition system, gas-exclusive speed regulator, fuel flow rate control valve, variable Venturi mixture. The system is also optimized by our company to achieve high reliability and efficiency.

    Alternator

    High performance, reliable and efficient brushless AC synchronized mecc alte ECO38 alternator is selected to ensure optimized performance of the generator set.

    Technical Parameters

    S.N.

    Item

    Specification

    1

    Genset

    260kW Natural Gas Generator

    1.1

    Model

    260kW

    1.2

    Rated Power

    260kW

    1.3

    Rated Current

    451A

    1.4

    Rated Voltage

    230/380V

    1.5

    Rated Frequency

    50Hz

    1.6

    Continuous Power

    210kW

    1.7

    Start Mode

    DC24V Electric Start

    1.8

    Regulation Mode

    Electric regulation

    1.9

    Fuel Control

    Lean-burn, close-loop control

    1.10

    Ignition

    Electronic control single cylinder independent high energy ignition

    1.11

    Operation Type

    One-button start/stop

    1.12

    Lubricant Consumption

    ≤0.3g/kWh

    1.13

    Power Generation

    ≥3.75 kWh/Nm³(Standard Natural Gas)

    ≥2.0 kWh/Nm³(Bio-gas with methane more than 55%)

    1.14

    Genset Dimension

    5500×3000×2800mm

    1.15

    Genset Weight

    6800kg

    2

    Engine

    2.1

    Brand

    HuaChai Deutz

    2.2

    Model

    V6

    2.3

    Displacement

    11.9

    2.4

    Intake

    Turbo-charger, forced inter-cooling, four-valve

    2.5

    Rated rpm

    1500

    2.6

    Cooling Method

    Water Cooling

    2.7

    Lubrication

    Pressurized splash lubrication

    2.8

    Lubricant Temperature

    ≤108℃

    3

    Alternator

    3.1

    Brand

    Mecc alte

    3.2

    Mode

    ECO38-2L4

    3.3

    Power Factor

    0.8(lag)

    3.4

    Generating Efficiency

    93.7%

    3.5

    Capacity

    300kVA

    3.6

    Phase

    3-phase, 4-wire

    3.7

    Insulation Grade

    H

    3.8

    Protection Grade

    IP23

    4

    Generator Set Control System

    4.1

    Brand

    DEIF

    4.2

    Model

    AGC200

    4.3

    Function of Controller

    One key start/stop, automatic monitoring/recording, multilevel protection

    4.4

    Displayer

    rpm / lubricant pressure/ water temperature/ running hours/ current/ voltage/ frequency/ battery voltage/ active power/ reactive power/ load distribution proportion

    4.5

    Protection

    Auto control and warning for high water temperature, low lubricant pressure, over-speed, over-current, ac/dc low or high voltage

    5

    Canopy

    Ski-mounted canopy, forced ventilation

    1. The parameters are based on low heat vale 35.88MJ/Nm3 fuel and conform to ISO8528/1, ISO3046/1, BS5514/1.
    2. The data is achieved at standard conditions: absolute atmosphere pressure-100kpa, ambient temperature :25°C,relative humidity: 30%.
    3. Under above condition, it conforms to DIN standard ISO 3046/1 rate. Tolerance of fuel consumption is ±5%.
    4. Generator set tested power factor is 0.8 and above.
