Small LCD Display Module 2.1 Inch HD Resolution With LED Backlight

Small LCD Display Module 2.1 Inch HD Resolution With LED Backlight

1 Handling Precautions

1.1.1 The display panel is made of glass. Do not subject it to a mechanical shock by dropping it from a high place, etc.
1.1.2 If the display panel is damaged and the liquid crystal substance inside it leaks out, be sure not to get any in your mouth, if the substance comes into contact with your skin or clothes, promptly wash it off using soap and water.
1.1.3 Do not apply excessive force to the display surface or the adjoining areas since this may cause the color tone to vary.
1.1.4 The polarizer covering the display surface of the LCD module is soft and easily scratched. Handle this polarizer carefully.
1.1.5 If the display surface is contaminated, breathe on the surface and gently wipe it with a soft dry cloth. If still not completely clear, moisten cloth with one of the following solvents:
－Isopropyl alcohol
－Ethyl alcohol
Solvents other than those mentioned above may damage the polarizer. Especially, do not use the following:
－Water
－Ketone
－Aromatic solvents
1.1.6 Do not attempt to disassemble the LCD Module.
1.1.7 If the logic circuit power is off, do not apply the input signals.
1.1.8 To prevent destruction of the elements by static electricity, be careful to maintain an optimum work environment.
1.1.9 Be sure to ground the body when handling the LCD Modules.
1.1.10 Tools required for assembly, such as soldering irons, must be properly ground.
1.1.11 To reduce the amount of static electricity generated, do not conduct assembly and other work under dry conditions.
1.1.12 The LCD Module is coated with a film to protect the display surface. Be care when peeling off this protective film since static electricity may be generated.
1.1.13 Storage precautions
1.1.14 When storing the LCD modules, avoid exposure to direct sunlight or to the light of fluorescent lamps.
1.1.15 The LCD modules should be stored under the storage temperature range. If the LCD modules will be stored for a long time, the recommend condition is:
1.1.16 The LCD modules should be stored in the room without acid, alkali and harmful gas.

2 Transportation Precautions
The LCD modules should be no falling and violent shocking during transportation, and also should avoid excessive press, water, damp and sunshine.

General Specifications

Absolute Maximum Ratings

Note:

Note1: Absolute maximum rating is the limit value beyond which the IC maybe broken.

They do not assure operations.

Note2: Background color changes slightly depending on ambient temperature.

This Phenomenon is reversible.

Ta≦70℃: 75%RH max

Ta>70℃: absolute humidity must be lower than the humidity of 75%RH at 70℃

Note3: Ta at -30℃ will be <48hrs, at 80 ℃ will be <120hrs

Electrical Characteristics

1) Driving TFT LCD Panel

Note: Voltage greater than above may damage the module.

All voltages are specified relative to VSS=0V.
