RT/duroid 6010 high frequency PCB Material properties and
processing technology
RT/duroid 6010 high frequency PCBs are ceramic-filled PTFE
composites designed for electronic and microwave circuit
applications requiring a high dielectric constant. They are ideal
for applications such as power amplifiers, high-frequency
oscillators, and filters, among others.
At Bicheng PCB, we specialize in producing high-quality RT/duroid
6010 PCBs. This capability ensures that our PCBs are manufactured
to the highest standards, resulting in a superior product that
meets our customers' needs.
One of the key advantages of RT/duroid 6010 PCBs is their high
dielectric constant of 10.2, which is essential for enabling
circuit size reduction. With a low dissipation factor of 0.0013 at
10GHz, these PCBs are ideal for use in high-frequency applications
operating at X-band or below.
RT/duroid 6010 PCBs also have a tight dielectric constant and
thickness control, resulting in repeatable circuit performance.
They offer excellent thermal stability, with a thermal coefficient
of dielectric constant (TCDk) of -140 ppm/℃, which is much lower
than other materials. This makes them suitable for use in
high-temperature environments.
In addition to their excellent electrical properties, RT/duroid
6010 PCBs also offer excellent mechanical properties. They have a
high modulus of elasticity, which makes them resistant to warping
and bending. They also have a low coefficient of thermal expansion
(CTE) in the X and Y directions, which means that they are less
prone to expansion and contraction when exposed to temperature
changes.
At Bicheng PCB, we can manufacture RT/duroid 6010 PCBs in various
types, including single-layer, double-layer, and multi-layer
boards. We can also provide hybrid types to meet our customers'
specific needs. Our RT/duroid 6010 PCBs have a wide range of
thicknesses, from 4mil to 125mil. We offer copper weight options of
1oz, 2oz, and 3oz.
To ensure that our RT/duroid 6010 PCBs meet our customers'
requirements, we use our advanced DFM capability to optimize our
manufacturing process. We carefully analyze each design to identify
any potential issues that could affect the performance of the PCB.
We then make the necessary adjustments to ensure that the PCB meets
the required specifications.
In conclusion, RT/duroid 6010 high frequency PCBs are an excellent
choice for high-frequency applications requiring a high dielectric
constant.
