Precise Controlling Systems 36-65kw Precision Air Conditioning Units For Large IDC

    Buy cheap Precise Controlling Systems 36-65kw Precision Air Conditioning Units For Large IDC from wholesalers

    Buy cheap Precise Controlling Systems 36-65kw Precision Air Conditioning Units For Large IDC from wholesalers
    • Buy cheap Precise Controlling Systems 36-65kw Precision Air Conditioning Units For Large IDC from wholesalers
    • Buy cheap Precise Controlling Systems 36-65kw Precision Air Conditioning Units For Large IDC from wholesalers
    • Buy cheap Precise Controlling Systems 36-65kw Precision Air Conditioning Units For Large IDC from wholesalers

    Precise Controlling Systems 36-65kw Precision Air Conditioning Units For Large IDC

    Ask Lasest Price
    Brand Name : Coolent
    Model Number : M535-765
    Certification : ISO/CE
    Price : to be Negotiated
    Payment Terms : T/T
    Supply Ability : 1000/Month
    Delivery Time : 4W
    • Product Details
    • Company Profile

    Precise Controlling Systems 36-65kw Precision Air Conditioning Units For Large IDC

    Precise Controlling Systems 36-65kw Precision Air Conditioning Units For Large IDC


    Product introduction

    The precision air conditioner is a special air conditioner designed for the computer room of modern electronic equipment. Its working accuracy and reliability are much higher than ordinary air conditioners. We all know that computer equipment and program-controlled switch products are placed in the computer room.

    Feature & Benefits

    Scope of Applications

    • Computer room and data center
    • Switch room and mobile center station in telecommunication
    • High-tech environment and lab
    • Industrial automation control room and precision manufacturing workshop
    • Standard test room and calibration center
    • UPS and battery room
    • Test room in hospital
    • Biochemical culture chamber

    Air Supply Method

    Advantages

    • High reliability, high energy saving rate, high adaptability, low cost throughout life
    • The air-conditioning unit adopts a modular design, the compressor and evaporator of a refrigeration system are in the same module, and the transportation and handling module is disassembled
    • No need to cut and weld copper pipe100% full frontal maintenance, saving space in the computer room
    • Mitsubishi/Hitachi inverter high-efficiency compressor
    • The indoor fans are equipped with EBM/Xerox Bai and other brand EC fans as standard, and the fan system saves more than 30% energy than conventional air conditioning units
    • Standard EEV dual electronic expansion valve, low-load dehumidification
    • Large area V-shaped evaporator, high air volume, high sensible heat ratio
    • Large humidification capacity, suitable for poor water quality, low maintenance
    • Frequency conversion series units are equipped with oil separator as standard
    • The power consumption per 1kg/h of humidification should not exceed 0.8kW to achieve energy-saving operation.

    Technical Parameters

    Model: CYAS20D/US23D/US26D/US28D/US31D/US35D/US40D/US45D/U
    Power Supply380V 3Ph-50HZ
    Air DischargeUpflow/Downflow
    Cooling Capacity :24℃/50%RH
    Total CapacityKW20.523.526.828.331.535.540.245.6
    SensibleKW18.921.624.226.128.933.237.642.2
    AEERw/w3.73.63.63.73.73.73.73.6
    Air Flowm3/h6830765075808500920098001060012000
    Compressor Hermetic scroll
    RefrigerantR407C
    Compressor quantityPC11111111
    Fan Section Centrifugal fan (Optional EC)
    Fan quantityPC11111122
    Rated currentA2.52.52.83.23.54.14.44.9
    Rated powerW10501100120013001320200021502400
    Reheat CapacityKW66669999
    Reheat MaterialPTC
    Humidifier Section Electrode type
    CapacityKg/h555555513
    Rated CurrentA666666615
    Condensor Model58588080100120150150
