ASR6501 Smart IoT LoRa Transmitter Module 434Mhz LoRa Wan Module

    Buy cheap ASR6501 Smart IoT LoRa Transmitter Module 434Mhz LoRa Wan Module from wholesalers

    Buy cheap ASR6501 Smart IoT LoRa Transmitter Module 434Mhz LoRa Wan Module from wholesalers
    • Buy cheap ASR6501 Smart IoT LoRa Transmitter Module 434Mhz LoRa Wan Module from wholesalers
    • Buy cheap ASR6501 Smart IoT LoRa Transmitter Module 434Mhz LoRa Wan Module from wholesalers

    ASR6501 Smart IoT LoRa Transmitter Module 434Mhz LoRa Wan Module

    Ask Lasest Price
    Brand Name : Cansec Wireless
    Model Number : ASR6501
    Price : USD 4.90$ per piece
    Payment Terms : T/T
    Supply Ability : 20000000 units per year
    Delivery Time : 5-8 weeks
    • Product Details
    • Company Profile

    ASR6501 Smart IoT LoRa Transmitter Module 434Mhz LoRa Wan Module

    Industry Use 434/470/868/915Mhz Cansec LoRa Wan Module LRW2020 ASR6501 Smart IoT LoRa Transmission Module

    Parameter
    Min
    Typ
    Max
    Unit
    Operating Voltage
    1.8
    3.3
    3.7
    V
    Operating Temperature
    -20
    -
    +70
    Current
    Consumption
    Sleep Mode(Without RF Config Retention, with RTC)
    -
    3
    4
    uA
    Receive mode
    -
    12
    -
    mA
    Transmit Mode (@+20dBm, Carrier)
    -
    120
    -
    mA
    TX Power (For Carrier)
    -
    20
    21
    dBm
    RX Sensitivity (For Lora Modulation)
    -
    -
    -140
    dBm
    Distance
    2
    Km

    Industry Use 434/470/868/915Mhz Cansec LoRa Wan Module LRW2020 ASR6501 Smart IoT LoRa Transmission Module


    LRW2020UA-A module is designed based on SX1262 and MCU which is a general LoRa Wireless Communication Chipset.The module with an AT instructions firmware, easy to use, reduce the development process of personnel.


    Applications
    Smart meters
    Supply chain and logistics
    Building automation
    Agricultural sensors
    Smart cities
    Retail store sensors
    Asset tracking
    Street lights
    Parking sensors
    Environmental sensors
    Healthcare
    Safety and security sensors

    FAQ

    Q1: Are you a factory or trade company?
    A1: We are a professional factory with 25 years experience.
    Q2: Can you accept OEM/ODM?
    A2: Sure, we have rich OEM&ODM experience.
    Q3: Do you have quality assurance?
    A3; Each of our products has undergone quality testing and has two years of free after-sales service.
