    Semtech LoRa 433Mhz LLCC68 Wifi Transmitter And Receiver Module

    Ask Lasest Price
    Brand Name : Cansec Wireless
    Model Number : Semtech LLCC68
    Price : USD 2.95$ per piece
    Payment Terms : T/T
    Supply Ability : 20000000 units per year
    Delivery Time : 5-8 weeks
    • Product Details
    • Company Profile

    Semtech LoRa 433Mhz LLCC68 Wifi Transmitter And Receiver Module

    Cost Effective Cansec LoRa 433Mhz Wireless RF Receiver Transceiver Module LR68Na-C Semtech-Llcc68 LoRa Module IoT Solutions


    Parameter
    Min
    Typ
    Max
    Unit
    Operating Voltage
    1.8
    -
    3.7
    V
    Operating Temperature
    -20
    -
    +70
    Current
    Consumption
    Sleep Mode
    -
    0.5
    1.5
    uA
    Receive mode
    -
    4.9
    -
    mA
    Transmit Mode
    -
    120
    -
    mA
    TX Power (For Carrier)
    -
    20.5
    21
    dBm
    RX Sensitivity (For Lora Modulation)
    -
    -
    -148
    dBm

    Cost Effective Cansec LoRa 433Mhz Wireless RF Receiver Transceiver Module LR68Na-C Semtech-Llcc68 LoRa Module IoT Solutions



    1. The LR68-NA-C module is sub-GHz radio transceivers that are ideal for long-range wireless applications. These devices support LoRa® modulation for LPWAN use cases and (G) FSK modulation for legacy use cases. The devices are highly configurable to meet different application requirements utilizing the global LoRaWAN® standard or proprietary protocols.

    2. The devices are designed to comply with the physical layer requirements of the LoRaWAN specification released by the LoRa Alliance™.
    3. The radio is suitable for systems targeting compliance with radio regulations including but not limited to ETSI EN 300 220, FCC CFR 47 Part 15, China regulatory requirements and the Japanese ARIB T-108. Continuous frequency coverage from 150 MHz to 960 MHz allows the support of all major sub-GHz ISM bands around the world.
