The MCA4 board is mainly used for spectral analysis, APE and power
detection.
For detailed functions and features, refer to Table 1.
Table 1 Functions and features of the MCA4 board
Function and Feature
Description
Basic function
Provides four ports and each of the ports supports spectrum
analysis of up to 80 wavelengths.
Detection function
Supports monitoring of the following information and reports to the
SCC board. The following information can be displayed on the U2000.
Optical power of each wavelength
Central wavelength
Number of wavelengths in the main optical path
Supports 10 Gbit/s, 40 Gbit/s, 100 Gbit/s, and 200 Gbit/ssignal
OSNR detection when the Port OSNR detection license (OD V1) or Optical Doctor management system license is used and the OD functions are configured.
When neither the Port OSNR detection license (OD V1) nor the Optical Doctor management system license is used, there are the following restrictions if 40 Gbit/s or
higher rate wavelengths are deployed in the system:
OSNR monitoring is not supported if adjacent channels have 50 GHz
channel spacing spacing.
OSNR monitoring is supported only for 10 Gbit/s or lower rate
wavelengths if the channel spacing is 100 GHz.
OSNR monitoring is supported for all signals if their rates are 10
Gbit/s or lower, regardless of whether the Port OSNR detection license (OD V1) /Optical Doctor management system license is used.
NOTE:
If the power deviation between some wavelengths monitored by the
MCA4 board exceeds 6 dB, then the wavelength with lower power may
be regarded as noise and cannot be scanned by the MCA4 board.
OSNR monitoring is not supported for PID boards.
APE function
Supported
Detects the optical power of each wavelength.
Optical-layer ASON
Supported
MCA4 Specifications
Specifications include optical specifications, dimensions, weight,
and power consumption.
Optical Specifications
Table 1 lists the optical specifications of the MCA4 board.
Table 1 Optical specifications of the MCA4 board
Item
Unit
Value
Operating wavelength range
nm
1529-1561
Detect accuracy for central wavelength
nm
±0.1
Channel spacing
GHz
50/100
Detect range for single channel optical power
dBm
-30 to -10
Detect accuracy for optical power
dB
±1.5
OSNR detection accuracy A (The OSNR of 10 Gbit/s signals can be
detected.)
dB
±1.5 (OSNR: 13 to 19)
±2 (OSNR: 19 to 23)
OSNR detection accuracy Ba
dB
±1.5 (OSNR detection range: 13-23)
Numbers of optical interface
pcs
4
a: The OSNR detection function is available only when the Port OSNR detection license (OD V1) or Optical Doctor management system license is used and the OD functions are configured.
Mechanical Specifications
Dimensions of front panel (H x W x D): 264.6 mm (10.4 in.) x 50.8
mm (2.0 in.) x 220 mm (8.7 in.)
Weight: 1.9 kg (4.2 lb.)
Power Consumption
Board
Typical Power Consumption (W)
Maximum Power Consumptiona (W)
MCA4
8.0
8.5
a: The maximum power consumption is the power consumed by the board
when it works normally under the highest ambient temperature.
Available variants of the MCA4 board
Board
Variant
Description
TN11MCA4
01
Detects optical power and OSNR of 10 Gbit/s or lower signals.
02
Detects optical power of 100200 Gbit/s or lower signals.
Supports 10 Gbit/s, 40 Gbit/s, 100 Gbit/s, and 200 Gbit/s signal
OSNR detection when the Port OSNR detection license (OD V1) or Optical Doctor management system license is used and the OD functions are configured.
When neither the Port OSNR detection license (OD V1) nor the Optical Doctor management system license is used, there are the following restrictions if 40 Gbit/s or
higher rate wavelengths are deployed in the system:
OSNR monitoring is not supported if adjacent channels have 50 GHz
channel spacing spacing.
OSNR monitoring is supported only for 10 Gbit/s or lower rate
wavelengths if the channel spacing is 100 GHz.
OSNR monitoring is supported for all signals if their rates are 10
Gbit/s or lower, regardless of whether the Port OSNR detection license (OD V1) /Optical Doctor management system license is used.
