Seamless Precision Double Wall Bundy Tube 9.52x0.7mm EN10305-1

    Buy cheap Seamless Precision Double Wall Bundy Tube 9.52x0.7mm EN10305-1 from wholesalers

    Buy cheap Seamless Precision Double Wall Bundy Tube 9.52x0.7mm EN10305-1 from wholesalers
    • Buy cheap Seamless Precision Double Wall Bundy Tube 9.52x0.7mm EN10305-1 from wholesalers
    • Buy cheap Seamless Precision Double Wall Bundy Tube 9.52x0.7mm EN10305-1 from wholesalers

    Seamless Precision Double Wall Bundy Tube 9.52x0.7mm EN10305-1

    Ask Lasest Price
    Brand Name : Joyruns
    Model Number : 4.76*0.5,4.76*0.6, 4.76*0.7, 6*0.6, 6*0.7,8*0.6
    Certification : ISO9001,ROHS
    Payment Terms : L/C, T/T
    Supply Ability : 1500Tons/Month
    Delivery Time : 10days
    • Product Details
    • Company Profile

    Seamless Precision Double Wall Bundy Tube 9.52x0.7mm EN10305-1

    Seamless Precision Double Wall Bundy Tube 9.52*0.7mm EN10305-1


    It is mainly used on refrigeration condenser and evaporator, brake tube, oil

    injection tube line and link pipe parts. It would be in coils and straight tube


    THE TYPE OF SURFACE COATING, CONDITION AND CODE STEEL TUBE


    type

    Coating condition

    code

    CU coated both sides a

    Cu coated on the outer and inner side both

    DWCuCu

    ZN coated outer CU,

    coated inner b

    Outer Zn coated, inner CU coated

    DWZnCu

    an electric or hot dip galvanized.

    b made by both sides CU coated steel coil. On the welding line ,to be negotiated


    Main size OD and thickness


    OD

    /mm

    Thciknes/mm

    0.50

    0.60

    0.65

    0.70

    0.80

    0.90

    1.00

    1.20

    3.18

    4.00

    4.76

    5.00

    6.00

    6.35

    7.94

    8.00

    9.53

    10.00

    12.00

    12.70


    The tolerance allowed of the ODof the steel tube


    OD

    The tolerance allowed

    (based on no coating)

    < 4.76

    ±0.05mm

    4.76 ~ 8.00

    ±0.08mm

    > 8.00 ~ 12.00

    ±0.10mm

    > 12.00 ~ 18.00

    ±0.12mm


    The tolerance allowed of the thickness of the steel tube


    thickness

    The tolerance allowed

    (based on no coating)

    0.50

    ±0.07mm

    0.70

    ±0.08mm

    1.00

    ±0.09mm

    1.30

    ±0.10mm


    WORKING SHOP



    Laboratory Testing Equipment




    PACKING
