    White Refractory Ceramic Crucibles Graphite Melting Crucible For Drying Burning

    Ask Lasest Price
    Brand Name : ZG
    Model Number : MS
    Certification : CE
    Price : USD10/piece
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000 pieces
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    White Refractory Ceramic Crucibles Graphite Melting Crucible For Drying Burning


    Crucibles (ceramic crucibles, graphite crucibles, refractory crucibles)


    Ceramic Crucibles, Graphite Crucibles, Refractory Crucibles,For Drying, Burning, Melting Or Heating


    We offer a range of crucibles suitable for calcinating and melting various alloys.The main quality of a crucible is its ability to withstand temperatures above the melting temperatures of the alloys deposited by metallurgists without altering or polluting the molten metal. In some cases, when a crucible is brought to these very high temperatures, it must be strong enough to withstand being moved for the casting of parts (bronze foundry for example).

    Crucibles (ceramic crucibles, graphite crucibles, refractory crucibles) are containers for drying, burning, melting or heating various substances for use in metallurgy, glass industry, growing crystals, laboratory equipment, various high-temperature equipment.


    Our team is available to help you choose the crucible and the material that best meet your requirements.


    Related Data


    Main component99%Al2O3S-SiCZrO2Si3N4
    Physical
    Property
    Densityg/cm33.93.163.2
    Water Absorption%00.100.1
    Sinter Temperature°C1700220015001800
    Mechanical
    Property
    Rockwell HardnessHV1700220013001400
    Bend Strengthkgf/mm23500400090007000
    Compression IntensityKgf/mm230000200002000023000
    Thermal
    Property
    Maximum working
    temperature
    °C1500160013001400
    thermal expansion
    coefficient
    0-1000°C
    /°C8.0*10-64.1*10-6(0-500°C)9.5*10-62.0*10-6(0-500°C)
    5.2*10-6(500-1000°C)4.0*10-6(500-1000°C)
    Thermal Shock resistanceT(°C)200250300400-500
    Thermal ConductivityW/m.k(25°C31100325
    300°C)16100325
    Electrical
    Property
    Resisting rate of Volume◎.cm
    20°C>1012106-108>1010>1011
    100°C1012-1013>1011
    300°C>1012>1011
    Insulation Breakdown
    Intensity
    KV/mm18semiconductor917.7
    Dielectric Constant (1 MHz)(E)10297
    Dielectric Dissipation(tg o)0.4*10-3

    Technical Ceramics offers crucibles from the following materials:

    • aluminum oxide (corundum, alundum, high-alumina ceramics);
    • zirconia;
    • silicon carbide;
    • graphite and graphite-containing materials;
    • graphite with pyrolytic coating;
    • pyrolytic boron nitride;
    • quartz ceramics and quartz glass;
    • refractory ceramics;
    • refractory composite materials;
