G100 Chain Block Lifting

    Buy cheap G100 Chain Block Lifting from wholesalers

    Buy cheap G100 Chain Block Lifting from wholesalers
    • Buy cheap G100 Chain Block Lifting from wholesalers
    • Buy cheap G100 Chain Block Lifting from wholesalers

    G100 Chain Block Lifting

    Ask Lasest Price
    Brand Name : VITALI-INTL
    Model Number : VIT10
    Certification : CE, GS, ISO 9001
    Price : Call or Email for quote
    Payment Terms : T/T, L/C
    Supply Ability : 10,000 pcs per month
    Delivery Time : Within 45 days after order confirmation
    • Product Details
    • Company Profile

    G100 Chain Block Lifting

    1 tonne Chain Block VIT-II
    Heavy duty type for professional & industrial users
    Chain Block type VIT-II is heavy duty type manual chain block for professional and industrial users.
    The hoists are manufactured by VITALI-INTL Lifting Equipment Ltd, based on European and American standards.
    The whole series of Chain Block type VIT-II contains 0.5 tonne, 1 tonne, 1.5 tonne, 2 tonne, 3 tonne, 5 tonne, 10 tonne, 20 tonne and 30 tonne in load capacity. They are mainly exported to American and European markets.
    Standard Features
    1. Meets all pertinent world standards
    2. Lightweight high strength grade 100 alloy steel load chain
    3. Compact design for limited headroom applications
    4. High strength steel frame and gear case built to be durable for the rugged needs of construction and maintenance rigging
    5. Heat-treated spur gear efficiently designed to provide smooth load handling and low hand chain pull
    6. Reinforced double pawl brake system and larger dia. pawl springs ensure reliable brake
    7. Open frame design for self-cleaning, quick load sheave inspection and easy hoist maintenance
    8. Caged roller bearings on load sprocket
    9. Zinc plated load chain
    10. Cast safety latches
    11. Cr plated side plate assemblies
    12. Thrust bearings in bottom hook assembly
    VITALI-INTL Chain Block VIT-II Specification
    Capacity(tonnes)0.511.522335102030
    Product No.VIT05VIT10VIT15VIT20VVIT20VIT30BVIT30VIT50VIT100VIT200VIT300
    No.of Falls111111224812
    Load Chain(mm)5x156.3x197.1x217.1x218x249x277.1x219x279x279x279x27
    Load Chain Grade100100100100100100100100100100100
    Pull to Rated Load 1(N)296415415525434449406415410410x2410x2
    Pull to Rated Load 2(N)237366366519395410357380410410x2410x2
    Proof Load(tonnes)0.751.52.253.03.04.54.57.515.025.037.5
    Hand Chain(mm)5x22.2x18 / 5.5x23.6x19
    Standard Lift(m)33333333555
    Net Weight(kg)912.214.515.52134224089.4214.7278
    Gross Weight(kg)9.412.7151622.234.522.741.596.9225.7293
    Extra weight per meter(kg)1.421.731.971.972.582.763.074.718.2316.4623.5
    Dimensionsa(mm)127147147147179182147179179207350
    b(mm)144157174174204263206263367873694
    c(mm)2853153403553805504756007408701,300
    f(mm)273333.5373743.543.551648282
    g(mm)354547525262.562.578---
    1: without Caged Roller Bearings on Load Sprocket (Standard Feature)
    2: with Caged Roller Bearings on Load Sprocket (Optional Feature)
    About VITALI-INTL Lifting Equipment Ltd
    VITALI-INTL Lifting Equipment Ltd, is one of the most advanced manual hoist factories in Asia. The company has registered the trademark with "VITALI-INTL" in Mainland China, Hong Kong China and some overseas countries.
    The company's philosophy of management and quality control are based on European and American standards.Their high quality manual hoists are mainly exported to American and European markets.
    The heat treatment and load chain production are the most critical production processes of the company. Additionally, they are equipped with advance scientific testing instruments, metallographic microscope, measuring projector, salt spray tester, endurance test machine and destruction test machine up to 100 tonnes.
    Anfeng Lifting & Rigging is authorized distributor for all the products made by VITALI-INTL Lifting Equipment.
    About Anfeng Lifting & Rigging
    Based in Shanghai Free Trade Zone, Shanghai Anfeng Lifting & Rigging Ltd. is an experienced technical and sales company specialized in supplying webbing slings, round slings, wire rope and slings, chains, rigging accessories and more.
    Anfeng supplies steel wire ropes, wire rope slings, lifting chains and accessories, webbing slings, round slings, fall protection harness, typhoon resistant series products, lashing, offshore mooring lines, chain hoists, lever hoists, electric hoists, shackles up to 1500t, and lifting points.
    With 20 years of experience in lifting and rigging industry, Anfeng not only provides customers with high-quality lifting and rigging products, but also provides complete lifting solutions according to different projects, such as technical consultation, solution design, product planning, onsite assistance and after-sales support.
