SH6602 Liquefied petroleum vapor pressure tester
An overview
SH6602 LPG vapor pressure tester is designed and manufactured
according to GB/T6602 "LPG vapor pressure measurement method".
It is suitable for liquefied petroleum gas whose boiling point is
higher than 0℃, volume content of hydrocarbon is less than 5%, and
its vapor is not more than 1550kPa at 37.8℃.
| Product model | SH6602 |
| Product Name | Liquefied petroleum Vapor pressure tester |
| Manufacturer | Shandong Shengtai Instrument Co., Ltd |
Testing items | Applicable to the detection of liquefied petroleum gas with a
boiling point above 0 ℃, a hydrocarbon volume content of less than
5%, and a vapor of no more than 1550Kpa at 37.8 ℃ |
| Compliant with standards | GB/T6602 Determination of Vapor pressure of Liquefied Petroleum Gas |
| Simple technical features or parameters | Temperature control accuracy:±0.1℃ |
Functional characteristics
1. The instrument consists of a temperature control device, a
heating device, a stainless steel bathtub, a stirring device, etc.
2. The temperature control device of the instrument adopts digital
display temperature controller, which has high temperature control
precision and is easy to operate. The output adopts Solid-state
relay, which has no contact, spark, noise, long service life and
reliability.
3. The instrument can perform two sets of experiments
simultaneously, improving work efficiency.
4. The instrument uses a pump to circulate and stir evenly, without
any noise, allowing the projectile to receive uniform temperature.
5. The instrument has a reasonable structure, convenient operation,
and beautiful appearance.
II. Technical parameters
| Power supply | AC220V±10% 50Hz |
| Heating power | 1.8KW |
| Stirring motor power | 15W |
| Temperature control accuracy | ±0.1℃ |
| Pressure gauge | circular pointer pressure gauge 0 ~ 2.5Mpa
|
| Temperature control range | room temperature ~ 70℃ |
| Package size: 48 * 45 * 75cm weight 50kg |
Packing list
| S/N | Name | Unit | Quantity | Remarks |
| 1 | Vapor pressure meter | set | 1 | |
| 2 | Steam bomb | set | 2 | |
| 3 | Pressure gauge | piece | 2 | |
| 4 | Mercury thermometer | piece | 1 | |
| 5 | Instruction | copy | 1 | |
| 6 | Packing list | copy | 1 | |
| 7 | Certificate warranty card | copy | 1 | |
Company Introduction
Shandong Shengtai Instruments Co., Ltd. is specialized in the
research and production of experimental testing instruments and
industrial testing instruments. It is a professional instrument
company integrating instrument research and development,
manufacturing, sales and service. Its products are widely used in
food, flour, grain and oil, Feed, electricity, petrochemical,
industrial oil, aerospace, coal quality and other industries.
For more than 10 years, Shengtai has always been adhering to the
"first-class service, customer first" as the purpose, "reasonable
price, honesty and trustworthiness" as the business policy. Adhere
to technical innovation, with rich knowledge of the technical team
and experienced, thoughtful after-sales service team.
Shengtai instrument as one of the most large-scale and competitive
enterprises in the industry, with the strength of technology
research and development, professional technical knowledge and
innovative design concept, in the model improvement, Significant
technical breakthrough has been achieved in the development of
function expansion and intelligent control system.
OUR service
After-sales service commitment, our company to sell the product
after-sales service commitment: warranty period of one year,
long-term technical support outside the warranty period. During the
warranty period, the seller shall bear the cost of the replacement
of the equipment, the freight and maintenance of the instrument;
outside the warranty period, the seller shall waive the maintenance
fee and charge only the cost of the basic materials and freight
charges when the instrument is malfunctioning and the seller shall
not charge the maintenance fee during the warranty period.
Packaging & Delivery
1. Out packing: Standard export wooden case.
2. Inner packing: With careful stretch film wrap product, hard wood
board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your
goods.
4.Port Any port of China
Lead Time :
| Quantity(Sets) | 1 - 1 | 2 - 5 | 6 - 10 | >10 |
| Est. Time(days) | 6 | 20 | 30 | To be negotiated |
