Product discription
Temperature And Humidity Test Chamber Completely independent system separate for testing in high
temperature, low temperature and constant temperature&humidity
environment.
This Chamber can simulate different environment condition.It's appropriate for testing material performance, such as resist
heat, resist dry, resist humidity and resist cold. That can define
performance of material.
Mainly used in national defense industry, aviation industry,
automotive parts, electronic components, plastics industry, food
industry and other related product development, straightening
management engineering test specifications. Its characteristics are
as follows:
1. The import of compressors and refrigeration accessories by the well-known brands in the national boundaries ensures the
stability of the refrigeration system.
2. The cause of the faults can be displayed and the reason is easy
to exclude.
3. The special air supply cycle design, the temperature and
humidity distribution uniformity is good.
4. The whole series of imported microcomputer controllers are
colored. Color touch screen, Chinese and English system, can be
used as a function of setting the city value. It can show the cause
of the trouble, exclude easy, super quiet design, effectively
reduce the running noise of the equipment, and
5. Super quiet design, effectively reduce the running noise of the
equipment.
6. Multiple safety protection, refrigerant high voltage protection,
compressor overload protection, current overload protection,
overtemperature protection, leakage protection.
Features:
1. sales in more than 80 countries
2. CE certification
3. PLC control system
4. Long service life
5. Size customization
6. Appearance material customization
Equipment summary:
Environmental Constant Temperature Humidity Climatic Test Chamber
is applied to test the materials in heat-resistance,
cold-resistance, dry-resistance, moisture-resistance. It is simple
to operate and program easy to edit. It can show the set values and
operative time.
Applicable industries:
Environmental Constant Temperature Humidity Climatic Test Chamber
applied to control the product
quality, such as electronic, plastic products, electrical
appliances, instruments, food, vehicles, metals,
chemicals, building materials, aerospace, medical care and so on.
Detailed Parameters:
| Model | BT-80 (A~G) | BT-150 (A~G) | BT-225 (A~G) | BT-408 (A~G) | BT-608 (A~G) | BT -800 (A~G) | BT-1000 (A~G) |
| Inside size WxHxD (cm) | 40x50x40 | 50x60x50 | 50x75x60 | 60x85x80 | 80x95x80 | 100x100x80 | 100x100x100 |
| Outside size WxHxD (cm) | 100x170x87 | 105x175x97 | 115x190x97 | 135x195x115 | 145x185x137 | 145x210x130 | 147x210x140 |
| Temperature range | -70ºC~+100ºC(150ºC)
(A:+25ºC B:0ºC C:-20ºC D:-40ºC E:-50ºC F:-60ºC G:-70ºC) |
| Humidity range | 20%~98%R.H.(10%-98%R.H/5%~98%R.H is the specific condition) |
| Accuracy/ uniformly | ±0.1ºC;±0.1%R.H./ ±1.0ºC;±3.0%R.H. |
| Accuracy / volatility | ±1.0ºC;±2.0%R.H./ ±0.5ºC;±2.0%R.H. |
| Heating / cooling time | About 4.0ºC/min;about 1.0ºC/min(5~10ºC/mm is the specific
condition) |
| Inside material | Stainless steel SUS 304# |
| Insulation material | High-temperature high-density amino acid ethyl ester foam
insulation materials, |
| Cooling system | Air-cooled/ single-stage compressor(-20ºC) ,wind, water
cooled/two-stage compressor(-40ºC~-70ºC) |
| protection | compressor overload switch, high and low pressure protection
switch, over-humidity-temperature protection switches, fuses,
warning system |
| accessories | recorder(purchase),view window,50mm testing hole,PL
lamp,clapboard,Dry and wet gauze ball |
| controller | TEMI300 digital controller from South Korea |
| compressor | France Tecumceh |
| power | 1Φ 220VAC±10% 50/60Hz & 3Φ 380VAC±10% 50/60Hz |
