Automatic Single Head Aluminium Profile Cutting Machine Window Section Feeding Corner Key

Aluminum Window Profile Auto Feeding Corner Key Single head Cutting saw Machine

Detailed Product Description:

Main Application:

Mainly used for aluminum alloy profile cutting, also can be used for plastic profile cutting.

Adopting durable hard alloy saw blade, diameter up to 20 ", high linear speed, high precision machining.

When the machine is working, the saw head can be placed in the angle of 90 degree ~45 degree.

The positioning dimension is high accurate. So, it is more suitable for cutting aluminum alloy profiles.

Main Technique Parameter:

1. Cutting Length------------------------------80~2080mm/3080mm

2. Cutting Width X Height--------------------230x150mm/280x100 mm

3. Main Motor Power--------------------------2.2kw

4. Main Motor Rotating Speed--------------2850r/min

5. Saw Blade Size------------------------------ф500xф30x120T

6. Swing Angle of Saw Blade----------------90°~45°

7. Feeding Speed of Saw Blade-------------0~3m/min

8. Returning Speed of Saw Blade-----------2~3m/min

9. Working Air Pressure------------------------0.6~0.8Mpa

10. Working Voltage----------------------------415V/50Hz

11. Overall Size(L X W X H)--------------1000(5200)x1300x1350mm

12. Weight-----------------------------------------900kg

PSL (Wuhan)  has rich experience in design, manufacture and sales more than 25 years. We are one integration supplier focussed on Sheet metal processing equipment, Metal pipes of profiles machining, Lasers application and kinds of automatic production lines.  such as 1) NC/CNC Press Brakes, 2) NC/CNC Shears, 3) Laser Cutting machine, 4) Laser Welding machine, 5) Rolling machine, 6) Punching Press, 7) Ironworker, 8) Duct production line, 9) Cut-to-length production line, 10) Slitting line, 11) Foam Sealing Spraying machine, and so on.

With high effective communication and quality service in mind, we strive to bring even better products to our clients through our continuous effort and a crew dedicated towards improvement.

With customizations from our own in house design, Our machinery are made efficient and reliable with rigorous testing. We strive to provide our clients with an pleasant  experience with our after-sale service. PSL will always be the comerstone and partner of your career.

We are always looking forward to work and grow with you.
