Rain Test Chamber For Automobile Lamp Shell Protection
SUS#304Stainless Steel Plate
The rain test box is suitable for external lighting and signal
devices and automobile lamp shell protection, can provide realistic
simulation of electronic products and components during
transportation and use may be subjected to a variety of environment
such as water and spray test. In order to detect the waterproof
performance of various products.
Rain test box is mainly used in electronic, electrical, aerospace,
military and other scientific research units of external lighting,
signal devices and car lamp shell protection test.
Waterproofing test class:
There are waterproof testing requirements for portable, outdoor and
automotive electronics. IEC, MIL, ETSI and SAE have formulated
corresponding testing requirements internationally.
IEC/EN60529 Waterproofing is divided into 9 classes (Class 0 to
Class 8), waterproofing classes (e.g. IPX4- Waterproofing class 4)
:
Level 0: completely waterproofing without protection
Level 1: Vertical dripping should have no harmful effect
Level 2: When each vertical plane of the case is tilted within the
range of 15°, the vertical dripping shall have no harmful effect
Level 3: Water is sprayed within 60° of each vertical plane,
without harmful effects
Level 4: Splashing the shell in all directions has no harmful
effect
Level 5: Spraying water in all directions to the enclosure has no
harmful effect
Level 6: Spraying water strongly in all directions to the enclosure
has no harmful effect
Level 7: The water intake into the shell will not reach the harmful
degree after immersion in the water under the specified pressure
for the specified time
Level 8: The water intake of the casing will not reach harmful
Level after continuous diving under conditions agreed by the
manufacturer and the user (which shall be harsher than Level 7)
Level 9: High voltage test
Meeting Standards:
IEC 60529
Model:
| Model | B-LY |
Internal Dim(mm) | custom |
| SOT(mm) | undetermined |
| structural features | Radius of arc pendulum tube | 400mm |
| Right Angle pendulum tube length | 500mm |
| Water jet pressure | 50-400kpa |
| Right Angle swing pipe spray diameter | 16mm |
| Water tank material | High-grade stainless steel plate |
The main technical parameters:
IP6 &UL1598, the external structure: a closed chamber
Inside diameter (L×W× H): 1960 x 1960 x 1900mm
Accessories:
- Circulation pump: 1 pc (can be adjusted)
- Digit flow meter: 4pcs ( to record the pressure of 4pcs spray
heads)
- Exhaust fan : 2pcs
- Water filter: 1 set
- UL 1598 standard spray head: 3pcs
- Nozzle: IP6 1 pc, IP5 1pc
- Water tank: 1 set
- Fixture: 1 set
- Adjuster(to adjust height of nozzle): 1 fixture
- Chamber (L×W× H): 1.96 * 1.96 *2.25 m
- IP 6 nozzle (water flow rate: 12.5l/min±5%, nozzle diameter:
12.5mm):
- The internal structure (accord with UL 1598):
Structure of EN/ UL Rain test chambers:
1,The outside layer is composed of the high quality stainless steel
plate, the inner container is the composed of stainless steel tabula rasa.
2, Large area of visible glass door, easy to observe the test
specimens in the testing chamber
3,The button is made of high quality of tank, can be fixed PU
activities wheel, it is convenient for user moved.
4, With 270 degree swing pipe and 360 degrees whorl pole water jet
device.
5, Adjustable speed samples stage.
Features of EN/ UL Rain test chambers:
- Rotating rain and spray nozzles designed to JIS specifications
- Speed control for the rotating spray nozzles
- Stationary product shelf - A rotating shelf is optional: see
options
- Water pressure regulators, gauges and flow meters
- Special high-volume floor drain system to rapidly drain water out
of the chamber
- Interior chamber size is the smallest possible area using the JIS
specified nozzles
Other sizes and capabilities available upon request. Please contact
us with your application.
