    Long Cylindrical 50mm Length Pin IEC 61032 Test Probe 12

    Ask Lasest Price
    Brand Name : HJ
    Model Number : HT-I08
    Certification : calibration certificate (cost additional)
    Price : Negotiatable
    Payment Terms : T/T, L/C
    Supply Ability : 30 sets / per month
    Delivery Time : 3 days
    • Product Details
    • Company Profile

    Long Cylindrical 50mm Length Pin IEC 61032 Test Probe 12

    IEC61032 Test Finger Probe Figure 8 Test Probe 12 With 50mm Length Pin


    Standard:

    IEC 61032 ‘Protection of persons and equipment by enclosures – Probes for verification’ figure 8 test probe 12.


    Application:

    Other access probes to verify protection of persons against access to hazardous live parts or hazardous mechanical parts.

    This pin is intended to be used on appliances for verifying the inaccessibility of hazardous live parts or hazardous mechanical parts which are liable to be touched accidentally by a tool, for example a screwdriver or similar pointed object in normal use.


    Feature:

    It can be used for enclosure protection test when open threaded hole of M6 at the end of the handle (connected with pull and push gauge).


    Parameters:

    ModelHT-I08
    Name

    Long Pin Test Probe 12

    Test Finger Probe

    Metal pin diameterФ4±0.05
    Metal pin length50±0.15
    Baffle diameterФ25±0.2
    Baffle thickness4
    Handle diameterФ10
    Handle length20
