Product Description
| Product Name | variable frequency induction motor |
| Ambient Temperature | -15℃~40℃ |
| Altitude | Less than 1000m |
| Frequency | 50Hz, 60 Hz or customized |
| Voltage | 380V, 660V or customized |
| Insulation class | F |
| Protection class | IP55 |
| Centre height of frame | 80~355 |
| Duty | Continuous |
| Motor Enclosure Design | Totally Enclosed |
| Frame material | Cast Iron |
| Appearance color | Green/Grey/Black/Blue/customized |
Product introduction:
UAMT80A series motor mainly applied to the glass processing
industry, glass edge grinding, glass shaping filed.
1, Use high accuracy bearings, axial float & radial run-out ≤
0.01mm, 100% products passed dynamic balance detection, ensured low
vibration and low temperature rising.
2, Grinding head direct connected to the motor, powerful!
3, The motor coil is dipped in vacuum environment, Class F
insulation, longer lifespan.
4, Special water proof design sealing structure, with high
temperature resistant materials, specialized for all kinds of
working site.
5, Voltage: 380V/50HZ (Various voltage&frequency are available,
415V/380V/240/230V/220V/120V/110V, 50HZ/60HZ)
UAMT80A Series motor Technical Parameters:
Model | Rated Power (Kw) | Rated Voltage (V) | Rated Frequency (HZ) | Rated Current (A) | Rated Torch (N.m) | Rated Speed (rpm) | Efficiency (η) | Power Factor | TS / TN | TMAX / TN | IS / IN | Weight (Kg) |
UAMT80A-2P-1.5 | 1.5kw | 380V | 50HZ | 3.10A | 5.0 | 2830r /min | 81.9% | 0.89 | 3.3 | 3.3 | 6.6 | 26kg |
UAMT80A-2P-1.75 | 1.75kw | 380V | 50HZ | 3.60A | 5.9 | 2830r /min | 82.3% | 0.90 | 3.1 | 3.0 | 6.6 | 26.1kg |
UAMT80A-2P-2.2 | 2.2kw | 380V | 50HZ | 4.40A | 7.4 | 2840r /min | 84% | 0.91 | 3.6 | 3.4 | 7.4 | 28.0kg |
UAMT80A-2P-3.0 | 3.0kw | 380V | 50HZ | 5.82A | 10.0 | 2850r /min | 84.3% | 0.93 | 3.8 | 3.4 | 6.4 | 30.0kg |
UAMT80A-4P-1.5 | 1.5kw | 380V | 50HZ | 3.72A | 10.3 | 1385r /min | 77.5% | 0.77 | 3.3 | 2.7 | 5.3 | 26.5kg |
Electric Input: AC/380V/50HZ/3PHASE(Customized Service is
available) Protection Level: IP54/Working Mode: S1/Insulation Class: F/Cooling
mode: IC411/Noise70/Vibration Level:N |
COMPANY INTRODUCTION
CDQC specializes in the research and development, manufacturing,
sales and service of various types of motors, covering an area of
20,000 square meters and having nearly 200 formal staff. We have a
professional research and development team. They are constantly
committed to the development and innovation of motor technology and
our staff accepting serious training can use advanced motor testing
platform and other professional testing equipment so that the
quality of products have greatly improved. We have to ensure to
provide customers with the highest quality and the most credible
motor for their machine. At present, CDQC has developed into a new
energy transmission base integrating materials, industry and trade.
