CCD Visual Control PCB Glue Dispensing Machine For Precise SMT
Dispensing
PCB Glue Dispensing Machine Overview:
PCB gule Dispensing machine in addition to complete the work of
precision dispensing, it can also be through the control of its
dispensing path for dispensing, if with different colors of glue,
then dot glue out of the pattern also has a beautiful effect. There
are many problems to be aware of when using PCB automatic
dispensing machine to automate dispensing. The first is the
viscosity of the glue problem, glue viscosity is not enough will
cause the package bonding is not firm, glue ratio is too large and
there will be the phenomenon of drawing trailing. Secondly, the
elimination of glue bubbles is also a compulsory course before
packaging operations, the need for operators and packaging
equipment technology to work together. At present, the PCB
automatic dispensing equipment on the market has been able to solve
this problem very well.
PCB Glue Dispensing Machine Features:
This machine is computer control with CCD visual positioning
system, which is suitable for precise dispensing and coating.
We also use high quality parts to build the machine to ensure
reliability and accuracy.
Standard machine adopts servo motor and screw drive, with muli-axis
design.
Dual tables to improve capacity for high volue production.
It is used pneumatic injection/piezoelectric/screw/AB rubber valve,
according to different dispensing materials.
The desktop design has small footprint.
The most important is that machine cost is economic.
1. Adopting computer control, Windows operating system, fault sound
and light alarm, and menu display
PCB Glue Dispensing Machine Specification:
| Model | SMTDR6 |
Working area X/Y/Z(mm) | 200*400, Dual Tables |
Max load Y-axis/Z-axis | 10kg/5kg |
Moving speed X&Y/Z(mm/sec) | 0.1-800/500 |
| Relolution | 0.01mm/Axis |
| Repeatability | ±0.01mm/Axis |
| Program capacity | No Limit |
| Data storage type | PC Windows 10 |
| Coating Capacity | 30CC |
| Display | LCD |
| Number of axis | 4 |
| Programming method | Visual programming |
| Valve nozzle cleaning device | Optional |
| Valve | Different valves are available for different applications |
| Warranty | 1 year |
| Tables | 2 |
| OS | Windows 10 |
| Software | Friendly |
| Programs | No limit |
| Camera | Yes |
| Power | AC110V/220V |
| Working tem. | 5-50℃ |
| Power Rate | 2.5KW |
| Air pressure | ≥ 0.65Mpa |
| valve quantity | 1(standard) |
| Working Humidity | 20-90% no condensation |
Dimension (W*D*H)mm | 950*850*850 |
| Weight(Kg) | 150 |
PCB Glue Dispensing Machine Dispensing Material:
Anaerobics, Coatings, Cyanoacrylates, White Glues, Epoxy Resin,
Greases, Sealants, Silicones, Solder/Braze Pastes, Thermal Grease,
Conductive Adhesive, Red Gum, UV Glue, AB Glue, Polyurethane Resin
Adhesive, etc.
After-Sales Service:
1. From the purchase date, one year free warranty, lifelong
maintenance.
2. Provide technical update and technical service at any time.
3. Software system life - long free upgrade, to ensure the latest
version of the software and perfect functions.
4. Provide technical training according to customer needs.
5. Make phone calls and on-site visits to customers from time to
time, communicate with customers and improve related problems in a
timely manner.
6. Provide door-to-door service, one-on-one designated service
policy.
