HWASHI 7 Axis 3D CNC Wire Bending Machine For 2 - 6mm / 3 - 8mm Wire

    Buy cheap HWASHI 7 Axis 3D CNC Wire Bending Machine For 2 - 6mm / 3 - 8mm Wire from wholesalers

    Buy cheap HWASHI 7 Axis 3D CNC Wire Bending Machine For 2 - 6mm / 3 - 8mm Wire from wholesalers
    • Buy cheap HWASHI 7 Axis 3D CNC Wire Bending Machine For 2 - 6mm / 3 - 8mm Wire from wholesalers

    HWASHI 7 Axis 3D CNC Wire Bending Machine For 2 - 6mm / 3 - 8mm Wire

    Ask Lasest Price
    Brand Name : HWASHI
    Model Number : CNC-HS-7-60/80
    Certification : CE
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets per month
    Delivery Time : 15 - 30 working days after received your payment
    • Product Details
    • Company Profile

    HWASHI 7 Axis 3D CNC Wire Bending Machine For 2 - 6mm / 3 - 8mm Wire

    CNC 7 Axis 3D Bending Machine for 2-6mm 3-8mm 5-12mm wire

    Product description

    CNC 7 Axis 3D Bending Machine for 2-6mm 3-8mm 5-12mm wire is used for iron wire, steel wire, stainless steel wire and non-ferrous metal wire (round, square, flat line), which will be suitable for bending the shape like square, round, hexagonal, oval with irregular shape and a variety of flat buckle, and all kinds of hooks.


    Features

    1. Computer startup, shutdown speed is fast, simple and convenient to operate, support multi-language operation, the computer interface can adjust the speed and change the program at the same time of production.
    2. The configuration adopts the imported high-precision and high-speed servo motor, imported reducer, stable and durable
    production speed which is 30% higher than the domestic counterparts of the same kind of products.
    3. The production process can achieve no change in the Angle when the Angle is folded at different speeds, and the production stability is better.
    4. Bearings, gear and other important parts of the imported parts, 9125 hours of warranty, durable and reliable equipment.
    5. High precision, can be made within the range of 3.0-8.0 mm wire diameter products, the error is reduced to 0.1mm

    Intelligent Bending Control System

    Automatic bending by inputting coordinate data of bending position. Easy operation

    Straightening Roller

    Use to straightening the feeding wire. Be able to process the wire diameter ranging from 2-6mm, 3-8mm and 5-12mm

    Cam Type 3D Bending Machine

    We will recommend you the suitable bending machine as per your product desig

    Cam-Free 3D Bending Machine

    We will recommend you the suitable bending machine as per your product design.

    Technical Data of 3D Wire Bending Machine

    Model

    CNC-HS-7-80

    CNC-HS-7-60

    Wire diameter

    3.0-8.0mm

    2.0-6.0mm

    Axis number

    7 axis

    7 axis

    Wire feed length

    infinite

    infinite

    Maximum wire feed speed

    100m/min

    100m/min

    Maximum feed length

    Infinite

    Infinite

    Wire feed instruction value

    ±0.01-±9999.99

    ±0.01-±9999.99

    Wire feed shaft servo power

    2.7KW

    2.7KW

    Wire switching shaft servo power

    2.7KW

    1.2KW

    Torsion shaft servo power

    2.7KW

    0.75KW

    Lifting platform servo power

    2.7KW

    0.75KW

    Cutting shaft servo power

    2.7KW

    0.75KW

    Torsion lifting platform servo power

    2.7KW

    0.75KW

    Core-switching shaft servo power

    2.7KW

    1.2KW

    Input voltage

    380V

    380V

    Computer specifications

    Industrial computer

    Industrial computer

    Process data storage

    More than 2000

    More than 2000

    Air pressure system

    Air pressure

    5-6KG/cm

    5-6KG/cm

    Probe

    Three

    Three

    Machine size

    Length

    4100mm

    2900mm

    Width

    2000mm

    900mm

    Highly

    1900mm

    1800mm

    Machine weight

    4300KG

    3000kg

    Application and samples

    We can provide customized service for you. Our engineers will discuss the specific welding requirement with you and come out with the suitable technical proposal based on your samples or drawings.

    Specification

    Other Machines Related to Wire Shelf Production Line Composition

    We can design the complete full automatic or semi automatic production line machine for refrigerator wire shelf. You may provide us the detailed product drawings and efficiency requirement. Then our engineering team will prepare the customized proposal for you.

    Wire Flattening and Cutting Machine

    This machine is able to process the round wire into flat wire. It will automatically feed the round wire and cut it into required length.
    Normally you will need to prepare the 8mm wire coil, and make it into 12x3mm flat wire strip.


    High Speed Wire Straightening and Cutting Machine

    This machine will help to make batch production of 2mm to 4mm wires. This machine speed is almost 5 times than the normal speed wire cutting machine. It helps to increase production rate and reduce labor cost.


    Wire Frame Bending Machine

    This machine helps to bend the flat or round wires into square shape wire frame. It is able to bend multiple wires at the same time so as to increase production rate.

    Wire Frame Butt Welding Machine

    The number of welding heads is depends on the welding width of the mesh. Different welding head can be set different welding programs and current respectively.

    Wire Frame Double T-Butt Machine

    This machine is used to weld the cross bars of the wire shelf to the wire frame. The double head design helps to increase the production rate. Easy Operation. We can also design the automatic moving and welding application.

    Wire Edge Trimming Machine

    After Welding, we need the trimming machine to cut off the edge of wire from the wire frame. To make the surface clean and smooth.


    2D Wire Handle Bending Machine

    This machine is used to bend the wire handle. It is suitable for 2-6mm wire bending. And you can bend any shape of the wire without changing mould.

    3D Wire Bending Machine

    This machine is used to bend the wire into 3D shape. It is suitable for 2-6mm or 3-8mm wire bending. And you can bend any 3D shape of the wire without changing mould.
