Brand Name : | Zhongli |
Model Number : | ZL-5002 |
Certification : | ISO,CE |
Price : | Negotiable |
Payment Terms : | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
Supply Ability : | 100 sets per month |
Delivery Time : | 5 days after the order confirmed |
Pilling and Snagging Testing Machine, Roll Box Pilling Tester
Applicable Range
Used for pilling test of fabrics ( woollen jersey especially )
under no pressure.
Relevant Standards
GB/T4802.3 ISO 12945.1 BS5811 JIS L1076 IWS TM152
Instrument characteristics
1. Imported rubber cork,Polyurethane sample carrier tube;
2. The inner rubber cork is a removable design;
3. Non-contact photoelectric counting , liquid crystal displaying.
Technical parameters
Model | ZL-5003 |
Balling box quantity | 2 piece |
Size of inner case | 235×235×235mm |
Case speed of revolution | 60±2r/min |
Counting range | 1~99999 times |
Sample carrier tube | external dimension Φ30×140 mm |
2 piece /case | |
Power source | AC 220V±10% 50Hz 120W |
External dimension(mm) | 1200×500×500mm |
Weight(kg) | 93 |
![]() |
