    ASTM D6055 Package Horizontal Compression Clamp Handling Testing Machine

    ASTM D6055 Package Horizontal Compression Clamp Handling Testing Machine
    Product Overview
    The ASTM D6055 Package Horizontal Compression Tester ISTA Packing Clamp Handling Testing Machine simulates the process of package discharge from schnabel cars. During this process, the clamping force from both boards affects packages and cargo. This test evaluates the resistance properties of packages against clamping forces.
    This equipment is suitable for testing packaging of kitchenware, furniture, household appliances, toys, and other finished products. It is particularly designed for clamping strength tests required by SEARS in the United States.
    Applicable Standards
    • ISTA 6 SERIES: Member Performance Tests
    • ASTM D-642
    • ASTM D6055
    Technical Specifications
    ParameterSpecification
    Max. Force1200kg (customized)
    UnitKgf/N/Lbf
    MotorServo Motor
    Clamping pressure force400~3000Lb (adjustable) according to transport diagram
    Clamping board size1200×1200mm
    Clamping board adjustable height0~1000mm
    Lifting speed10-305mm/min
    Clamping board expansion width200~2000mm
    Baseboard dimension1200×1200mm
    Accuracywithin ±5%
    Clamping board requirementFlat, parallel, non-deform under 2000Pound load; vertical alignment; thickness ≥25mm
    ControllerPC (Windows system) + software
    Safety featuresE-Stop, Over-load protection, Limit switches, Load sensor with automatic retreat
    Load cell4 pcs
    ProtectorLeakage protection, travel limit device
    PowerAC380V, 50Hz
    Weight1800kg
    Machine size2810 × 1900 × 2100mm
