Brand Name : | ZL |
Model Number : | ZL-5038 |
Certification : | ISO |
Price : | Negotiable |
Payment Terms : | T/T, Western Union |
Supply Ability : | 100 set per month |
Delivery Time : | 7-10 days |
USE:
This machine is suitable for the abrasion resistance test of
various webbings. The sample and the 6.35mm hexagonal rod are
rubbed at a certain angle and the effect of the wear is judged
under a certain number of revolutions.
Features:
1. A variety of angles to make your test accurate and productive.
2. LED digital display counter, you can set the number of tests
arbitrarily, and visualize the actual
number of tests.
Technical Parameters:
Working stations | 4 Station ( can test 4 sample per one time) |
Speed | (30 ± 1) times/min |
One-way travel | 305 ± 25mm |
Drum diameter | 406mm |
Angle | 85 ° ± 2 ° |
Test load (g) | (0.91±0.06) kg, (1.81±0.06) kg, (2.4±0.06) kg |
Machine size | about 1100 × 750 × 1000mm |
Power | 220V/5A or specified |
Weight | about 160kg |
![]() |
