Dual Function HELLA Smart Control Time Delay Relay 5DF 980 818-01
1. Product Detail
This smart controller is designed to simplify the installation of
HELLA’s LED Safety DayLights™ range by eliminating the need to wire the lamp, or changeover
relay to ignition terminal 15.
The Smart Controller can be wired directly to the positive terminal
of the battery, which saves the difficult and often time consuming
task of finding the ignition feed.
The smart controller monitors the voltage supply from the battery
and will automatically switch on when the engine is started, and
automatically switch them off when the headlamps are activated, or
the engine is turned off.
2. Diagram and Wiring
3.Parameter
Voltage | suitable for 12 and 24 volt systems. |
Maximum Continuous Load | 20W |
To Suit | HELLA LED Safety range. |
Features | OFF delay of approximately 10 seconds. |
Wiring Specifications | Terminal Number | Connect to | 30 | Battery (+) | 31 | Earth return (-) | 86 | Front position or headlamps (+) | DL1 & DL2 | Safety DayLights™ (+) |
|
4. Excellent production equipment
5. Package
Nowadays, package is important, we have various packing methods for
your selection.
You can also customize your package, as long as the quantity is
considerable.
6. Guarantee
To make you rest assured about the after-sale,we would like to
provide one-year quality guarantee.10000times life time .
