Product name: Digital textile printing machine with pigment ink for cotton
fabric
Product Feature:
1. Direct Print image into fabric
2. This machine with print and heat in one machine Save price and
save place.
3. It is adopt EPSON printhead with high precision.
4. This machine max print width 3.2m
Applications:
Interior Home Decoration: Print on polyester fabric to make windows
curtain and Tablecloth, sheets and so on.
Outside: Advertising materials to make flag,roll up banner, act
fast show and so on.
Specifications:
Model | CSR3200 |
Print head | Piezo technology, Epson print head |
Ink | Sublimation Ink,Reactive ink and Pigment Ink |
Color Mode | Dual CMYK |
Nozzles | (180 nozzles*8 lines)*3 heads |
Print Head Height | 1.5mm/6mm(adjustable) |
Ink Supply Mode | Continuous Ink Supply |
Max Material Width | 3300mm |
Max Printing Width | 3200mm |
Roll Owter Diameter | 3 Inch |
Max Weight For Roll Material | 100KG |
Interface | USB3.0 |
RAM | 128M |
Printer Power | 380V |
Power | Direct Dye Sublimation Heater 3500W
Printer 2000W |
Environment | temperature 20-32 degree |
Weight | 1120KG |
Machine working speed:
Printing resolution and speed
| Resolution(dpi) speed |
| 360*1800dpi(3 pass) 65m2/h |
| 720*1220dpi(4 pass) 45m2/h |
| 720*1800dpi(6 pass) 35m2/h |
Automatic feeding and collecting structure:
1,Intelligent infrared heater and fan drying system;
2,The machine through different quality tests is stable and
competent enough for mass production requirement.
3,No Pinch roller, let the fabric no wrinkle and print smoothly
4,Keep the fabric good air permeability after sublimation
5,Printing groove designed specially for fabric printing to collect
waste ink and keep
fabric clean.
6,Patented ink tanks keep ink supply constantly.
Competitive Advantage:
• Lower investment cost,3.2 meters width machine more usability
• One time molding mechanism design, reflect the stability and
reliable of textile printer
• High speed
• Automatic high precision feeding system, make sure that the exact
stationary into the cloth long figure carefree
• Using the sublimation ink, compatible with the advertising
industry in backlit mode. more environmental, more beautiful
effect.
Rip Software:
1. Onyx rip sofware easy to complete the Photos / vector
data,replacement of RGB / CMYK,and can easily to achieve color
change.
2.Colorful color replacement function can easily reproduce the
required color.
Our Support:
(1) 12-month warranty
(2) Free techinical traning
(3) On-site service
(4) Sample free
(5) Lifetime maintenace
After Sales Service:
1. With one year warranty and lifelong technical support.
2. Offer Video and operation manual, and the professional technical
staff online guidance.
3. Guarantee prompt warranty service for main parts repairment and
replacement by international courier
