    PE Construction Corrugated Pipe Extruder Machine Round HDPE Pipe Extruder Machine

    Ask Lasest Price
    Brand Name : WingsPlastic
    Model Number : SJ70/32
    Certification : CE
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10 sets
    Delivery Time : 45 working days
    • Product Details
    • Company Profile

    PE Construction Corrugated Pipe Extruder Machine Round HDPE Pipe Extruder Machine

    Round HDPE PE Construction Corrugated Pipe Extruder Machine Round HDPE Pipe Extruder Machine

    1.Single screw extruder especially used for polyolefine material possess effective plasticizing effect and high extrusion speed.

    2.The special detached type compounding screw an die head with spiral structure&reasonable channel are applicable to produce pipes with smooth inside and outside face.

    3.Unique calibration and cooling mode is capable of producing pipe with diameter from Φ50 to Φ200mm,production speed is up to 0.4~1.5m/min.

    4.All kind of polyolefine material,multi-layers spiral strengthening pipe can be co-extruded,recycled materials can be used in production;

    5.Optimum spiral copper sizing sleeve,its entrance carrying pre-cooling and powerful vacuum device to suit for high speed extruding pipe.

    6.Stainless steel cooling water trough is three-dimensional regulation,longitudinal moved by motor.

    7.High efficient cooling comes from peculiar spraying nozzle and high efficiency water pump.



    The Main Parameters of the machine:

    ModelSJ-65BSJ-90B
    L/D30:130:1
    Pipe Diameter(mm)50-10050-200
    Output(kg/h)20-6050-100
    Production speed (m/min)0.8-1.50.8-1.5
    Power (kw)32.750.2
