    900 KG High Voltage Portable Load Bank Digital Metering With Remote Control

    Reactive Load Bank
    Introduction
    Kaixiang offers a complete line of compact and portable load banks. They are constructed to the highest standards and designed to resist the vibration encountered during transportation. Our load banks provide high capacity testing.yet maintain a compact and reliable package.smaller kw models are available with handy carrying cases for maneuverability in the tightest spaces. Our portable load banks are perfect for operators that are load testing in multiple locations.
    Applications
    After setting generator rated power in software, system realize rapid loading through preset proportion, automatically and continuously load multiple power value and common tests, like stepping, full load, and over load, so that improve working efficiency.
    Technical Specifications

    Technical Parameters
    Rating Voltage/Frequency3 phase 3 wire, 240/480V/60Hz
    Max Load PowerResistive Load: 440kW (404KW @ 230/460V/60Hz)
    Load StepResistive Load:11 steps; 1,2,2,5,10,20,20,30,50,100,200kW
    Power Factor1
    Load Tolerance(each step)±5%
    Load Tolerance(overall)±3%
    Display Precision0.5 class
    Control Power SupplyInternal AC 230/460V/60Hz 3-Phase 3-Wire
    Wire Connection

    Load Power Supply Input——Copper bar (Delta connection Y)
    Control power supply input——Internal Connection

    Communication InterfaceRS485 (2)
    Insulation ClassF
    Working ModeContinuous Working
    CoolingForced air cooling,Horizontal inlet air,Horizontal outlet
    TransportationHoisting, there are lifting lug in top of case and wheel castors in bottom
    Chassis colorRAL7035
    Dimension

    Approximately; 1300*1600*1680
    (Width *Length *Height)

    Operating Environment Parameter
    Ambient Temperature-10℃~+50℃
    Relative Humidity≤95%
    Altitude≤2500 meters
    Atmospheric Pressure86~106kPa
    Main features
    Dual voltage

    Local or remote controls
    Standard data logging with
    Digital metering
    Designed to fit through man
    Doors and onfreight elevators
    Optional intelligent controls
    Wide range of nominal voltage and frequencies
    Horizaontal or vertical air discharge designs
    Indoor and outdoor construction
    Custom designs available
