Cellular Confinement System HDPE Geocell Tree Root Protection 150mm

    Buy cheap Cellular Confinement System HDPE Geocell Tree Root Protection 150mm from wholesalers

    Buy cheap Cellular Confinement System HDPE Geocell Tree Root Protection 150mm from wholesalers
    • Buy cheap Cellular Confinement System HDPE Geocell Tree Root Protection 150mm from wholesalers
    • Buy cheap Cellular Confinement System HDPE Geocell Tree Root Protection 150mm from wholesalers

    Cellular Confinement System HDPE Geocell Tree Root Protection 150mm

    Ask Lasest Price
    Brand Name : OEM
    Model Number : Plastic HDPE Geocell
    Certification : ISO certificate
    Price : USD0.58-USD3.06 per square meter
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 60, 000 Square Meters Per Day
    Delivery Time : 7-10 working days
    • Product Details
    • Company Profile

    Cellular Confinement System HDPE Geocell Tree Root Protection 150mm

    Cellular Confinement System Price Gravel Stabilizer Grid HDPE Geoceldas Price 150mm HDPE Geocell Price


    HDPE Geoceldas Description:


    Plastic HDPE geocell is three dimensional, honeycomb like structures manufactured from high density polyethylene and jointly welded by ultrasonic technique. It is flexible to fold during the transport and installation on construction site. The geocell nets will be filled with soils, granular, cements or other on-site infill materials when stretched into web structures, which has powerful and rigid confinement in the lateral and vertical sides.


    HDPE plastic honeycomb hdpe geocell gravel grid Features:
    1) Light material , resistant to wear , stable in chemical properties , anti-aging , resistant to acids and alkalis, applicable to different soil and desert and other geological conditions .
    2)High limit on lateral direction , anti-skidding , anti-deformation , effectively enhance the supporting ability and scattered load function of roadbed .
    3)High carrying capacity and good dynamic performance and high erosion ability .
    4)The geometry size can be changed to meet different needs of the project , such as height and welding distance
    5)Retractable and small loading volume , convenient joint , speed construction .
    6)Local material can be used during construction , reduce the construction cost , easy to be transported after folding together.


    Technical Parameters:
    Material PropertiesUnitTest Method
    Cell Depthmm75100150200
    Polymer Densityg/cm30.935-0.965ASTM D 1505
    Environmental Stress Crack ResistanceHours>400ASTM D 5397
    Environmental Stress Crack ResistanceHours6000ASTM D 1693
    Carbon Black Content%1.5% - 2.0%ASTM D 1603
    Nominal Sheet Thickness Before Texturingmm1.27 -5%,+10%ASTM D 5199
    Nominal Sheet Thickness After Texturingmm1.52-5%,+10%ASTM D 5199
    Strip Puncture ResistanceN450ASTM D 4833
    Seam Peel StrengthN1065142021302840EN ISO13426-1B
    Seam Efficiency%100GRI-GS13
    Nominal Expanded Cell Size (width x length)mm320x287,475x508 etc
    Nominal Expanded Panel Size (width x length)m2.56x8.35, 4.5x5.0, 6.5x4.5, 6.1x2.44

    FEATURES:
    1. High Grade Raw Material to Ensure the Product Performance
    Use virgin HDPE material to assure consistent, reproducible, and long-lasting performance.
    2. Ultrasonic Wedling to Ensure the Strength of the Seam
    Strong weld continually tested to project assurance.
    3. Honeycomb Structure to Bearing Heavy Load
    Prevent horizontal movement, and increase both shear strength and bearing capacity.
    4. Proformed Hole to Allow Water to Get Through
    Prevents erosion, and allow water flow.


    HDPE Geocell Application:

    1. Slope Protection
    The geocell Slope protection system prevents sliding or sloughing off by providing sufficient weight at the foot and or along the face of the slope.

    2. Earth Protection
    The geocell earth protection system minimizes and eliminates erosion actions of wind and water on exposed soils.

    3. Channel Protection
    The geocell channel protection system protects channel slops from soil erosion and confines the infill material that from the channel bed and banks.

    4. Ground Stabilization
    The Geocell Ground Stabilization System provides cost-effevtive solution to ground stabilization project.

    5. Vegetation Retention
    The Geocell Vegetation retention system`s horizontal create a natural environment for sustainable vegetation and allow water to collect through the wall fascia, and minimizing run off.



    FAQ

    1. how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    2.what can you buy from us?
    Geocell,Geogrid,Geomembrane,Geotextile,and other related products.

    3. why should you buy from us not from other suppliers?
    More than 20 years of production experience

    4. what services can we provide?
    Accepted Delivery Terms: FOB,CFR,CIF,EXW;


    Professional geosynthetics manufacturer
    Anhui Zhonglu Engineer Materials Co., Ltd

    Quality Cellular Confinement System HDPE Geocell Tree Root Protection 150mm for sale
