    Lithium Ion Battery Washing Test Chamber With PLC Touch Control Remote Control

    Ask Lasest Price
    Brand Name : DGBELL
    Model Number : BE-8109
    Certification : CE/ISO
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 500 Sets per Month
    Delivery Time : Negotiation
    • Product Details
    • Company Profile

    Lithium Ion Battery Washing Test Chamber With PLC Touch Control Remote Control

    PLC Touch Control Remote Control Lithium ion Battery Washing Test Chamber


    Lithium ion Battery Washing Test Chamber



    Application

    DGBELL’s battery washing test chamber consisting of test chamber and washing chamber under the test chamber. Moreover, it motorized rotary propeller mounted inside of the test chamber and on the internal wall of test chamber, the drying system is mounted. This battery washing tester is designed as a lifting structure chamber which forms a sealed casing when the washing chamber rises to the upper edge of the test chamber. The control panel and water tank are designed on the rack, and the washing chamber is connected to the water tank. Reasonable test chamber structure shortens the test period and improves test accuracy.

    The schematic diagram of the test device for the battery washing tester is as follows:

    Performance parameters

    Model


    BE-8109

    Instruction


    All-in-one structure, install explosion-proof lock + explosion-proof door
    Testing Rotary Plate Diameter500±10MM
    Inner Barrel Diameter650MM
    Inner Barrel Depth550MM
    Plate Rotation Speed Range1—900rpm/min controllable

    Speed Accuracy


    0.01

    Control System


    PLC touch control + Remote control

    Control Method


    Programmable, fully automatic testing.Returning to origin – adding water – raising – heating – dropping – soaking – stirring – draining – dewatering – de-cylindering – drying – complete.

    Servo Motor


    Japan Panasonic servo motor

    Time Setting


    0-999 hours (Adjustable)
    Liquid Temperature RangeRT+10℃ ~ 80℃(controllable)
    Water Temperature Deviation±2℃
    Water Temperature Accuracy0.1℃
    Water Temperature Heating RateRT ~ 45℃ ,Less than 40min
    Drying Temperature RangeRT+10℃ ~ 80℃(controllable)
    Wind Temperature Deviation±2℃
    Wind Temperature Display Accuracy0.1℃
    Wind Temperature Heating RateRT ~ 45℃ ,Less than 40min
    Water Control MethodAutomatic water pump
    Heating Control SystemHeating tube: water temperature control heating and thermostat control heating control separately
    Transmission SystemDriven by motor, screw drive control lift

    Alarm Device


    Tri-color warning light
    Observation Window370X350MM,Three-layers vacuum tempered glass

    Internal Material


    SUS 316# ,Stainless steel

    External Material


    1.5mm thickness Cold plate paint baked coating

    Power Supply


    AC 380V /14.0KW

    Total Dimension


    W1150 X H1780 X D1550 MM

    USB Interface


    With USB interface, test data can be output
