Sound Level Meter SL-5868P

    Buy cheap Sound Level Meter SL-5868P from wholesalers

    Buy cheap Sound Level Meter SL-5868P from wholesalers
    • Buy cheap Sound Level Meter SL-5868P from wholesalers

    Sound Level Meter SL-5868P

    Ask Lasest Price
    Brand Name : iqualitrol
    Model Number : SL-5868P
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 100 sets per month
    Delivery Time : 10 work days
    • Product Details
    • Company Profile

    Sound Level Meter SL-5868P


    Spec:Widely used to test the sound level of environment, machinery, vehicle, ship and other noise. For industrial environmental protection, construction, health care, teaching and research department.


    Features

    * Permits choice “A”, “C” , “F” weighting and “Fast” / “Slow” response times.

    * Offers 4 measurement parameters: Lp (sound level); Leq (Equivalent Continuous A Sound Level ); Lmax ( Maximum Sound Level) and LN (Percent of all readings over alarm value set ).

    * DC output :1 0 m V / d B.

    * Can memorize 30 groups of measurement results and measuring conditions.

    * Auto range selection and digital display with no guessing errors.

    * Use USB/RS-232 data output to connect with PC.

    * Provide Bluetooth data output choice.


    Specifications

    StandardsIEC 651.2, ANSI 1.4.2

    Paraments

    Measured

    Lp-Sound Level
    Leq-Equivalent Continuous A Sound Level
    Lmax-Maximum Sound Level
    LN-Percent of All Reading Over Alarm Value Set

    Testing

    Range

    Lp30~130dB(A Weighting)
    35~130dB(C Weighting)
    40~130dB(F Weighting)
    Leq30~130dB(10Seconds,1Min,5Min,10Min,15Min,30Min,1Hour,8Hours,24Hours)
    LN0~100%
    Resolution0.1dB
    Accuracy1dB
    Frequency Weighting‘A’/’C’/’F’*(Flat)
    Time WeightingFast (125 ms)/Slow (1 Second)
    Microphone1/2 Inch Electret Condenser Type
    Memory30 Group with Measuring Conditions
    Calibration Signal Built in94dB at 1k Hz(sinusoidal)
    Frequency Range20~12,500 Hz
    Alarm Value Set30~130 dB
    Alarm OutputLED Optional Relay Contact(NC)
    IndicatorLow Battery Indicator
    Power Supply4x1.5V AAA Size (UM-4)Battery
    External DC Power Supply6V,DC,100mA
    Dimensions236x63x26 mm
    Weight170 g

    Accessories

    Standard AccessoriesMain Unit
    Windscreen
    Carrying Case (B04)
    Operation Manual
    Optional AccessoriesND9 Sound Level Meter Calibrator
    RS-232C Data with Software
    Bluetooth Data Adapter with Software
