Our company has advanced technology and rich experience, by widely
absorbing the advanced technologies of domesctic and overseas,
thoroughly taking the processing needs of modern screw industry
into consideration, and keeping revising and improving.
Thanks to our adopting the latest processing technology, precise
assembly and debugging technology, and strict quality test, our
products are of good quality and stable performance.
I. General feature of CK6185E/2000 Lathe machine
1. This series of lathe machine have compact structure, good
appearance, big torque type chief shaft, high rigidity, stable
performance and good precision retaining ability.
2. Have optimum design of headbox, suitable for the lathe machining
of disc type and shaft type items, can have linear machining, arc
machining, metric thread and BSPT, multi-start thread machining,
also can have machining of complex shape and high accuracy
requirements type disc parts and shaft parts.
3. Machine guide rail and saddle guide rail are both made of
special material type hard rail, have high frequency quench,
superhard wear resistance, durable, can keep long time high
machining precision.
4. The digital system adopt GSK988T system, use Chinese famous
brand ball screw and high precision screw bearing.
5. Chief shaft use high precision shaft bearing group with
precision assembly and field balancing, to ensure the high
precision, low noise and strong rigidity of chief shaft.
6. All lubricant points use forced automatic lubricant device for
fixed point quantitative lubrication of screw shaft and railway.
Once have abnormal condition or lack of oil, it will have alarm
signal automatically.
7.Scraping device is fixed on railway to prevent corrosion by iron
scurf or cooling liquid, convenient for cleaning of iron scurfs.
II. Chief technical parameters
| No. | Item | Unit | Parameter |
| CK6185E/2000 |
| 1 | Max. swing over bed | mm | φ850 |
| 2 | X direction guide rail span | mm | 330 |
| 3 | Z direction guide rail span | mm | 600 |
| 4 | Max. swing over cross slide | mm | φ500 |
| 5 | Distance between centers | mm | 2000 |
| 6 | Weight of job between centers without steady | | Max.2Ton |
| 7 | Max. turning length | mm | 1950 |
8 | Height of center | Till machine body | mm | 425 |
| Till ground | mm | 1125 |
| 9 | Spindle bore | mm | φ105 |
| 10 | Bar diameter | mm | φ105 |
| 11 | Equipped with hollow chuck pull rod through hole | mm | φ88 |
| 12 | Spindle end type | | C11 |
| 13 | Chunk | mm | Normal 3 Jaw type φ400 |
| 14 | Taper of spindle taper hole | No | Metric 120, 1:20 |
| 15 | Spindle speed range | rpm | Manual 3gears(10 ~85, 40 ~ 350, 100~850) |
| 16 | Tailstock sleeve diameter | mm | φ100 |
| 17 | Inner hole taper for tailstock sleeve | No | MT6# |
| 18 | Travel length of tailstock | mm | 250 |
| 19 | Tailstock configuration | | Normal handle type |
| 20 | Number of electric tool holder | 把 | 4 |
| 21 | Cutter square size | mm | □32×32(four station) |
22 | Model of screw shaft | X direction | mm | FDC3205-P3 |
| Z direction | mm | FDC6310-P3 |
| 23 | X/Z axis fast move speed | m/min | 4/5 |
| 24 | X axis travel length | mm | 450 |
| 25 | Z axis travel length | mm | 2100 |
| 26 | Min. setting unit | mm | 0.001 |
| 27 | Chief motor power | KW | 11(frequency conversion) |
| 28 | Total power | KW | 18 |
| 29 | Machine weight | Kg | 5100 |
| 30 | Machine size(L*W*H) | mm | 4500×2000×2000 |
