1800mm EVA foam sheet splitting machine/eva slicing machine
Product Description
PE/EVA splitting machine is suitable for the highly and lowly
foaming and processing of rubber, PE and EVA, featuring high speed and high accuracy.
1. Easy operation, high speed, high precision, top level quality.
2. Tape blade holder have been tungsten hardened completely against
abrasive and distortion.
3. Easy and accurate automatic digital control the up & down
adjustment of wheels.
4. Mechanical gearbox for quick shift, steady output, low
malfunction.
5. Synchronized blade holder sliders to remain adjusted precision
after movement of blade holder.
6. Reinforced sliders to keep precision against material with high
hardness.
7. All electric control element are imported from Taiwan.
8. Drive bearings are imported to assure long life time and high
duration
| Item | Contents | Dimensions |
| 1 | Skiving width | 1800mm |
| 2 | Skiving Thickness | 0.3-100 mm |
| 3 | Skiving Hardness | 10°-80° |
| 4 | Skiving Speed | 10M-40 M/min |
| 5 | Skiving Precision | ±0.05 m/m Or ±5% |
| 6 | Drive Power | 11KW |
| 7 | Blade Belt Dimension | 1.0×90×8100m/m |
| 8 | Skiving Dimension | 3900×1150×2100m/m |
| 9 | Equipment Weight | About3000KG |
