Hot Sale Extremely Robust 17-4 SS Single Point Load Cell Force
Sensor 100-500kg Suitable For Industrial Weight Sensor
Features
Shear beam weighing Single Point load cell FA568 offers limitless possibilities for applications. The off-center weight sensor is available in six different ranges:50,100,200,300,500kg. The weighing sensor is waterproof to an IP68 rating, so it can be
applied to a variety of environments.
High precision
Stainless steel material, strong stability
High waterproof grade
Applications
Packing scale
Hopper scale
Industrial weighing system
Mounting Dimension-Single Point load cell Weight Sensor
| Specifications | Technique |
| Capacity | 50,100,200,300,500kg |
| Accuracy class | C3 |
| Rated output | 2.0±1%mV/V |
| Zero balance | ±2%F.S. |
| Non-linearity | 0.017%F.S. |
| Hysteresis | 0.017%F.S. |
| Repeatability | 0.017%F.S. |
| Creep(30min) | 0.01%F.S. |
| Temp.effect on output | 0.02%F.S./10℃ |
| Temp.effect on zero | 0.02%F.S./10℃ |
| Input impedance | 381±4Ω |
| Output impedance | 350±1Ω |
| Insulation | ≥5000MΩ/100VDC |
| Recommended excitation | 5~15V |
| Maximum excitation | 20V |
| Compensated temp range | -10~60℃ |
| Operation temp range | -20~80℃ |
| Safe overload | 150%F.S. |
| Ultimate overload | 200%F.S. |
| Cable size | Φ5.4×3000mm |
| Material | Stainless Steel |
| IP Class | IP68 |
The core team of Fibos has 20 years of experience in the design and
production of advanced sensors in Germany. We continuously develop
and produce: precision micro and small force sensors, single point
load cells, dynamic and static torque sensors, six-dimensional
force, three-dimensional force, multi-dimensional force sensors,
load cells, custom ring force sensors, thread force sensors, thread
preload force sensors, sensors for robots, tension series and
various non-standard force sensors, etc. The company produces
pressure force sensors: accurate measurement, low height, small
deformation, high precision, good stability, fast response, easy
installation, long life, complete specifications and sizes, not
only for push and pull meters, hopper scales, a variety of
industrial weighing systems, automotive press assembly, automated
assembly, 3C product testing; also used in new energy product
assembly, medical testing, textiles, robotics, mold assembly, wind
energy, nuclear power and ships, etc. The product dynamic response
frequency is high, also can accept custom specifications. In the
application of high-frequency loud, fatigue strength after the
test, life use up to 100 million times, suitable for all kinds of
aircraft, automotive testing occasions.
FAQ
Q1: How can I get the quotation?
Please send your inquiry to us. Click 'Contact Supplier' icon which
is on the left-side or write down your requirement at the bottom of
this page.
Q2: What detailed information do I need to provide if I want to
place an order?
We need to know the following information: Capacity, Usage and
other related parameters you need.
Q3: Do you have any discount?
Yes, we take bulk order, if you buy large QTY, please send us
inquiry, we can discuss the price.
Q4: Can I get samples?
Yes, if you have the follower orders, we could offer the samples or
free samples for you.
Q5: How about the quality of the products?
We have the certification of CE and RoHs , also we are the
Alibaba's verified supplier, you don't have to worry about this.
Q6: When will you arrange the production?
We will arrange the production immediately after receiving your
payment.
Q7: Could you provide me the shortest lead time?
We have materials in our stock, if you really need, let's discuss
and we will try our best to satisfy you.
