Specifications |
System |
CPU | Corte X A7 Quad core 1.6GHz, R16 |
Memory/RAM : | DDR3 1GB/2GB |
Memory/Flash: | 4G/8G/16G EMMC |
SD | support 32G SD card |
VIDEO | RMVB,MKV,MOV,WMV,AVI,MPG,TS with 1080P H.264 format etc. alomost
all format was supported |
AUDIO | MP3,WMA,WAV,OGG,FLAC |
GPS MODULE | Support GPS and Glonass |
OS | Android 6.0 |
Temperature | -20°C TO +70°C |
OS update | SD update |
APP update | SD update |
Logo update | SD update |
Navigation software | IGO, navitel, Sygic etc |
DVD decoder | SUNPLUS 8202TQ |
Screen | SUPPORT HD TFT (800*480/1024*600)and capacitive touch screen. |
FM IC | NXP 6624 with RDS |
WIFI | Build-in or External |
3G GPRS | External (optional)3G dongle |
TV | Optional Analog or Digital TV( DVB-T, ISDB-T,DVB-T2) |
Bluetooth | A2DP and Bluetooth OBD |
Steering Wheel control | Support (Some cars need CAN BUS |
Rear view video | Support Automative turn on when reversing' |
Power on | 16S~20S, high speed turn on system |
Power off | Rearly shut off the OS, <10mA |
work volt | DC12V |
Operate volt range | 10.8V ~16V |
Max current | 10A |
Form Factor | In-Dash |
Enclosure Type | 2 DIN |
Features | GPS, DVD, FM/AM, iPod, Bluetooth, RDS, Steering wheel control,
SD/USB multimedia palyback, Rear Camera Input, Aux In, |
Ill control | Yes |
Anti shock | Mechanical anti-shock & Electronic anti-shock |
Motorized slide-down Face | NO |
Panel Angle Control | NO |
Display |
Display mode | 16:09 |
Screen Size | 6.2; 7; 8; 9; 10.1; 10.4 inch |
Touch Screen | Capacitive touch screen |
Screen Resolution | 800*480/1024*600 |
