    OR Controller Source Selector Switch IC P-Channel 2:1 Automatic Switching Between DC Sources

    Ask Lasest Price
    Brand Name : Analog Devices Inc.
    Model Number : LTC4412ES6#TRMPBF
    Certification : ISO9001
    Price : $4.9
    Payment Terms : , Western Union, D/A, L/C, T/T
    Supply Ability : 50000 Acre/Acres per Day+pcs+2-5days
    Delivery Time : 2-4work days
    • Product Details
    • Company Profile

    OR Controller Source Selector Switch IC P-Channel 2:1 Automatic Switching Between DC Sources

    OR Controller Source Selector Switch IC P-Channel 2:1 Automatic Switching Between DC Sources


    PRODUCT DESCRIPTION


    The LTC®4412 controls an external P-channel MOSFET to create a near ideal diode function for power switchover or load sharing. This permits highly efficient OR’ing of multiple power sources for extended battery life and low self-heating.


    When conducting, the voltage drop across the MOSFET is typically 20mV. For applications with a wall adapter or other auxiliary power source, the load is automatically disconnected from the battery when the auxiliary source is connected.


    Two or more LTC4412s may be interconnected to allow load sharing between multiple batteries or charging of multiple batteries from a single charger. The wide supply operating range supports operation from one to six Li-Ion cells in series. The low quiescent current (11µA typical) is independent of the load current. The gate driver includes an internal voltage clamp for MOSFET protection.


    The STAT pin can be used to enable an auxiliary P-channel MOSFET power switch when an auxiliary supply is detected. This pin may also be used to indicate to a microcontroller that an auxiliary supply is connected. The control (CTL) input enables the user to force the primary MOSFET off and the STAT pin low. The LTC4412 is available in a low profile (1mm) ThinSOT package.


    The power good detection level and foldback current limit profile are internally preset for 5V (LTC4219-5) and 12V (LTC4219-12) applications.


    PRODUCT PROPERTIES


    Product Status
    Active
    Type
    Source Selector Switch
    FET Type
    P-Channel
    Ratio - Input:Output
    2:1
    Internal Switch(s)
    No
    Delay Time - ON
    110 µs
    Delay Time - OFF
    13 µs
    Current - Output (Max)
    -
    Current - Supply
    15 µA
    Voltage - Supply
    2.5V ~ 28V
    Applications
    Handheld, USB Powered Supplies
    Operating Temperature
    -40°C ~ 85°C
    Mounting Type
    Surface Mount
    Package / Case
    SOT-23-6 Thin, TSOT-23-6
    Supplier Device Package
    TSOT-23-6
    Base Product Number
    LTC4412
