    ODM Embedded Panel PC RK3568 Fanless Embedded Computer Industrial Box PC

    Ask Lasest Price
    Brand Name : LONGYU
    Model Number : AIoT-G68C
    Certification : CE RoHS
    Price : TBA
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 10000PCS/Month
    Delivery Time : 7-10 Work Days
    • Product Details
    • Company Profile

    ODM Embedded Panel PC RK3568 Fanless Embedded Computer Industrial Box PC

    Product Description


    Compact Industrial Box PC Fanless Embedded Computer RK3568


    CPU processor:RK3568 Cortex A55

    Operating System:Android11.0 / Linux4.4 kernel / Debian10 / Ubuntu18.04

    Running memory:DDR4 2GB

    EMMC:8GB EMMC NAND

    GPU:Mali-G52 1-Core-2EE

    HDMI:HDMI 2.0 support 4K output

    USB:2 vertical ports (USB 3.0x1 and USB 2.0x1), 4 horizontal ports (TYPE A), 1 built-in pin (USB 2.0)

    Audio interface:Support American standard 4 segment headset in one 3.5mm socket (left-right-ground MAC)

    Serial port:3*RS232 ,2* RS232/RS485/CAN Switching betweenN channels (Switching between jumper caps)


    Product Performance



    System

    CPU processor

    RK3568 Cortex A55

    Operating System

    Android11.0 / Linux4.4 kernel / Debian10 / Ubuntu18.04

    Running memory

    DDR4 2GB

    EMMC

    8GB EMMC NAND

    GPU

    Mali-G52 1-Core-2EE


    Port

    HDMI

    HDMI 2.0 support 4K output

    USB

    2 vertical ports (USB 3.0x1 and USB 2.0x1), 4 horizontal ports (TYPE A), 1 built-in pin (USB 2.0)
    Audio interfaceSupport American standard 4 segment headset in one 3.5mm socket (left-right-ground MAC)
    Serial port3*RS232 ,2* RS232/RS485/CAN Switching betweenN channels (Switching between jumper caps)
    Gigabit Ethernet interface2-Route 10 / 100 /1000 Mbps Ethernet port

    Source

    Power interface3 PIN*2.54mm terminal DC24V provides power supply
    Power input12V-24V

    Environmental Character istics

    Working temperature-10℃ ~ 60℃
    Storage temperature-20℃ ~ 70℃
    Operating humidity5-90 RH%
    TFSelf-ejecting TF card socket, up to 128GB TF card support
    SIM card1 Standard drawer-type interface with reserved eSIM interface
    RTC1 Road Hardware Clock
    WIFI/BT2.4G WIFI

    MiniPCI-E 4G

    MiniPCI-E 4G

    GPIO interface16* GPIO
