SCr440 Alloy Steel Plate JIS Standard Steel Plate & Sheets 41Cr4
Thickness 10.0 - 150.0mm
Products Specification of Steel Plate
| Products Name | AISI 5140 / 1.7035 Alloy Steel Plate |
| Thickness | 4.0 - 150.0mm |
| Width | 100 - 2200mm custom cutting any size as request |
| Length | 6m 8m 10m 11.5m 12m or cutting any length as request |
| Standard | ASTM JIS GB EN |
| MOQ | 500 Kgs |
| Deliver time | 7 - 14 days |
| Loading Port | Shanghai Port |
| Packing | wooden pallets |
| Other Grade | AR400 / AR450 / AR500 / AR600 NM400 NM450 NM500 NM600 |
| Service | Cutting, Heat treatment |
SCr440 alloy steel is a structural alloyed steel which contains
1.0% Cr as per JIS G4104 standard .Compared with S40C steel,it has
better strength and hardenability,but may crack when welding.
SCr440 is widely used in Low and moderately stressed parts for
vehicles, engines and machines where hard, wear resisting surface
is needed. The hardness as surface hardened can achieve to 54 HRC.
Chemical Composition of SCr440 Alloy Steel
| Grade | C | Mn | Si | Cr | P | S |
| SCr440 | 0.38-0.43 | 0.6-0.85 | 0.15-0.35 | 0.9-1.2 | ≤ 0.03 | ≤ 0.03 |
| 5140 | 0.38-0.43 | 0.7-0.9 | 0.15-0.35 | 0.7-0.9 | ≤ 0.035 | ≤ 0.04 |
SCr440 Steel Mechanical Property With Quenching and Tempering
| Tensile Strength | Yield Strength | Elongation | Reduction of Area | Impact Charpy-V | Hardness |
| ≥932Mpa | ≥784Mpa | ≥13% | ≥45% | ≥59J | 269-331HB |
We can also supply SCr440 Alloy Steel Round Bars
- Shape:Round / Square / Flat Bars, Shafts, Rollers, Blocks.
- Forged round bar
- Diameter: 80-1,000mm
- Length: 3,000-10,000mm
- Rolled round bar
- Diameter: 10-300mm
- Length: 3,000-10,000mm(can be customized)
- Forged square bar
- Size: 150×150-600×600mm
- Length: 3,000-8,000mm
- Surface condition: Black/Peeled/Smooth Turned
Our Cutting Service
- Cutting method: Plasma cutting
- Cutting tolerance: ±5mm
- Cutting Width: within 3000mm
- Cutting Length: within 12000mm
- Cutting Edge: Smooth without burr
