Product Description
solvent based adhesive coating leather fabric bonding machine
upholstery making machine
Application:
This solvent based adhesive laminating machine is widely used for
the bonding of many materials, such as
Fabric+ Fabric
Fabric+ Nonwoven...
Fabric+ Breathable Film (Membrane) such as PU film, TPU film, PTFE
film, PE film, OPP film, BOPP film, OPP film, PVC film, etc.
Luggage materials, such as EVA, PVC...
Diving Material, such as SBR, CR...
It is widely used in garments, shoe materials, automotive
interiors, sports products, bag/luggage, home textiles, decoration
materials, medical products, diving equipment industry, and many
other industries.
Features:
1. Applying special formulated solvent based adhesive makes the
finished products bonded firmly, durable, breathable, soft and
washable.
2. Special engraved roller along with precisely adjusted scarping
blade make sure the adhesive applied evenly onto the material
surface.
3. A layer of Teflon coated on the surface of the heating drum to keep
it clean, preventing the material from getting contaminated.
4. High-efficient heating rods in the heating drum can heating the
drum to 200 degrees in a short time, greatly accelerate the
evaporation procedure of solvent, improving the adhesion
performance.
5. High technology gas heating device can be equipped to greatly
reduce the electric consumption.
6. Equipped with advanced infrared edge alignment devices to keep
the materials in line.
7. User-friendly operation system is designed to make it easy to
handle this machine.
8. Automatic selvedge trimmer will be installed. If required,
automatic edge waste removing device can be added.
9. Length measuring device and rewinding device are installed on the
machine.
Main technical parameters:
Effective Width | 1800mm, 2000mm, 2200mm According to The Maximum Material Width |
Diameter of Heating Drum | 1500mm |
Width of Heating Drum | 1800mm, 2000mm, 2200mm According to The Maximum Material |
Heating Rods in Heating Drum | 30 PCS x 1.5KW |
Running Speed | 5-45 m/min |
Power | 50 KW |
Net Weight | 8500 KGS |
Dimensions (L*W*H) | 11500mm x 2500mm x 2500 mm |
