Wholesale Large Capacity Sand Filter for RAS Using in Aquaculture
Fish Farming.
Product Description
According to different media, the filter use and role are also
different.Media generally are quartz sand, activated carbon,
manganese sand, anthracite, etc. TPCF use activated carbon as
media, TPSF sand filter use quartz sand, TPMF use manganese sand to
remove iron, manganese. It can also be used in combination.
The main function is to remove suspended matter, mechanical
impurity, organic matter, reduce the turbidity of water,
adsorption, removal of pigment, residual chlorine colloid and iron
ion in water. It can be selected according to the amount of
filtration size, use and operation is very simple.
Features:
1.Easy operation, low maintenance
2.Effective for organic matter, oxide and metal ion
3.High effectiveness and compact structure
Advantages
1. The water nozzel adopts top quality V-slot filter element,with
precise slot size,extrmely smooth surface,easy to wash, not easy to
block, high strength and long service life,Easy to operate and
maintain.
2. Good filtration effect and compact structure.
3. The control mode: manual/Automatic.
4. Materials can be customized according to customer
requirements:FRP, carbon steel, SS304, SS316,etc.
Specifications
| Model | Vessel Hight(mm) | Equipment total height(mm) | Flow Rate(m3/h) | Inlet/Outlet(mm) |
| TPSF-1200 | 1500 | 2770 | 11 | DN65 |
| TPSF-1400 | 1500 | 2750 | 15 | DN65 |
| TPSF-1500 | 1500 | 2800 | 18 | DN65 |
| TPSF-1600 | 1500 | 2825 | 20 | DN80 |
| TPSF-1800 | 1500 | 2900 | 25 | DN80 |
| TPSF-2000 | 1500 | 3050 | 30 | DN100 |
| TPSF-2200 | 1500 | 3200 | 38 | DN100 |
| TPSF-2400 | 1500 | 3350 | 45 | DN100 |
| TPSF-2500 | 1500 | 3400 | 50 | DN125 |
| TPSF-2600 | 1500 | 3450 | 55 | DN125 |
| TPSF-2800 | 1500 | 3550 | 60 | DN125 |
| TPSF-3000 | 1500 | 3650 | 70-80 | DN125 |
| TPSF-3200 | 1500 | 3750 | 80-100 | DN150 |
*Above parameters only for reference, customized available for
detailed requirements
About us
Top machinery, founded in 2002, specialized manufacture wastewater
treatment equipment and sludge dewatering machine, like screw type
sludge dewatering machine, decanter centrifuge, brushing/scraping
self-cleaning filter, automatic back-flushing filter, Bernoulli
filter, electrocoagulation, inward/outward water micro filter, bar
screen, etc. With our consistent effort, high quality, competitive
price and good after-service, our machines are supplied to more
than 30 countries with very good feedback.
Customer Visitations and Exhibitions
With our consistent effort,Our machinery is supplied to more than
30 countries including the
Russia,Pakistan,India,Argentina,Indonesia,Romania,Canada,Turkey,Vietnam
and other countries. Also participate in the exhibitions of urban
sewage treatment, wastewater treatment,textile, leather, chemical
and other industries.
FAQ
Q: Are you trading company or manufacture?
A: We are both manufacture and trading company. We have over 20
years' professional experience as a RAS equipment
manufacturer and engineering service enterprise.
Q: What are your factory main products?
A: Automatic Drum Filter, Protein Skimmer, UV Sterilizer, Biological
Filter, Ozone Generator, Oxygen Generator Oxygen Cone, PP/PVC Fish
tank, Water Pump, Air Blower, Degassing, Sand Filter.
Q: Do you provide OEM service?
A: Yes. Any required logos is available.
Q: How could we trust you and your company? This is first time
transaction?
A: Our company has more than 20 years professional experience.. We
export nearly 40 countries all over the world. Welcome to our
company and watch our plant production condition any time.
Q: What certificates do you have?
A: ISO/SGS/Patent
Q: Do you offer after-sales service?
A: Yes. Engineers available.
Q: We haven't imported before, can you ship the goods to our
warehouse?
A: Yes. Although our normal trade term is EXW, FOB, CIF, we can
also arrange logistics to your warehouse.
Q: What is your MOQ?
A: Normally, our MOQ is 1 set.
Q: What about your delivery time?
A: Normally within 30 days against down payment.
