    Compact and User-Friendly Flexographic Printing Machine for Exercise Book

    Ask Lasest Price
    Brand Name : LIANDONG
    Model Number : LD1020YX
    Certification : CE Certificate
    Supply Ability : 5 Set/Sets per Month
    Price : $100,000.00/sets 2-2 sets
    • Product Details
    • Company Profile

    Compact and User-Friendly Flexographic Printing Machine for Exercise Book

    Flexographic printing machine for exercise book


    Product Application


    This machine adopts high techniques such as microcomputer control , electro-optical tracking, gas-liquid interaction, human-machine interface touch screen operation and ink flexographic printing as ink flexographic printing is environmentally-friendly and scientific. This production line is an ideal choice of mass production of staple-binding notebooks, with a perfect combination of 5 processes from reel one paper unwind , high speed flexographic printing with - 2/2 , paper cross cutting , collecting and finished sheets collect.


    Specification:
    Product Model LD-1020YX
    Web Width 580-1020mm
    Max.Printing Speed 300m/minute
    Repeat Range 300-670mm
    Cutting Length 300-670mm
    Counting & Collecting 5-50sheets
    Max.Reel Paper Diameter 1200mm
    Sheet Weight 45-120g
    Total Power 30kw
    Overall Dimensions (L X W X H ) 9300 X 2600 X 2300mm
    Machine Weight 7.5t
    flexographic printing machine for exercise book


    Main Features


    Function and features:
    Fully automatic, take it easy, accurate color, long life.
    1) Environmentally-friendly ink flexographic two colors printing
    2) Use motors, variable frequency speed control, saving electricity, small running fluctuations.
    3) Use special diagonal-tooth gear, accurate printing size.
    4) Printing rolls treated by dynamic balance, static balanced.
    5) Print produce are clear and good arrangement quality.
    6) Speed adjustable, suitable for variable paper


    Certifications
    Detailed Images

    Machine Parts

    Name: soft paper cover feeder

    Brand: wellmatic

    Original: China

    The paper cover feeder was developed by our factory.

    Main Features

    Name: saddle stitching head
    Brand: Hohner
    Original: Germany
    Made in Germany.

    Machine Parts

    Name: STAMPING ROLLER BEARING
    Brand: FAG

    Original: Germany
    We purchased the STAMPING ROLLER BEARING from Germany.

    Main Features

    Name: CUTTING SYNCHRONOUS BELT

    Brand: SOMGS
    Original: Germany
    We purchased the CUTTING SYNCHRONOUS BELT from Germany.

    Our Service

    Pre-Sales Service

    * Inquiry and consulting support.

    * Sample testing support.

    * View our Factory and our Customers' Factory.

    After-Sales Service

    * Training how to instal the machine, training how to use the machine free.

    * Engineers available to service machinery overseas.

    Packing & Delivery
    Packaging
    Size
    depends
    Weight
    depends



    Packaging Details

    The normal package is wooden box(Size: L*W*H).

    If need,the wooden box will be fumigated.

    If container is too tigher,we will use pe film for packing or pack it according to customers special request.

    The photo shows that we are loading the containers.

    Packaging
    Size
    pending
    Weight
    pending



    Packaging Details
    flexographic printing machine for exercise book


    If container is too tigher,we will use pe film for packing or pack it according to customers special request.
    If need,the wooden box will be fumigated.
    The normal package is wooden box(Size: L*W*H).
