Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor

    Buy cheap Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor from wholesalers

    Buy cheap Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor from wholesalers
    • Buy cheap Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor from wholesalers
    • Buy cheap Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor from wholesalers
    • Buy cheap Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor from wholesalers
    • Buy cheap Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor from wholesalers
    • Buy cheap Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor from wholesalers
    • Buy cheap Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor from wholesalers

    Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor

    Ask Lasest Price
    Brand Name : UNIVO
    Model Number : UBWP305
    Supply Ability : 1000 Piece/Pieces per Month
    Price : $66.00 - $82.00/sets
    • Product Details
    • Company Profile

    Customized UNIVO UBWP305Y Mechanical Arm Force Measurement Tension/Compression Sensor

    Product Description
    Hook scale and belt scale; Hopper scale, storage scale; Material tank; Material mechanics testing machine; labor safety testing equipment, etc;
    Rated Load
    0.2~50(kN)
    Comprehensive Precision
    0.02~0.05%F·S
    Sensitivity
    2.0 mV/V
    Creep
    ±0.02 %F·S/30min
    Zero Output
    ±1 %F·S
    Temperature Effect On Zero
    ±0.02 %F·S/10℃
    Temperature Effect On Output
    ±0.02 %F·S/10℃
    Operating Temperature Range
    -20℃~+65℃
    Input Resistance
    380±10 Ω
    Output Resistance
    350±3 Ω
    Insulation Resistance
    >5000 MΩ
    Safe Load Limit
    150%F·S
    Bridge Voltage
    Recommendation 10V DC
    Material
    Alloy Steel
    Load Cell Mode of Connection
    Input+:Red
    Input-:Black
    Output+:Green
    Output-:White
    Why Choose Us
    Details Images
    Company Profile
    Product packaging
    FAQ
    Q1. What are your packaging conditions? Answer: Usually, brown cardboard boxes are packaged with bubble bags inside to wrap the product. Q2. How long is your quotation valid? Answer: Our quotation is valid for 30 days. Q3. How is your delivery time? Answer: General standard type: 7-15 working days after confirming the order based on the quantity; Non standard types require communication and confirmation with us. Q4. What is your minimum order quantity? Answer: According to different product types, the cost varies and the minimum order quantity also varies. Please contact us for confirmation. Q5. How do you ensure good product quality? Answer: We have a complete quality control system; All of our products undergo a comprehensive inspection by the quality department before being shipped to customers. Q6. Can you produce based on samples? Answer: Yes, we can produce according to your samples or technical drawings. Q7. Can you accept OEM brands? Answer: Yes, we can accept OEM brands. Q8. How long is the warranty period for your product? Answer: Lifetime maintenance, 24 months of non human damage (calculated from the time of receipt), with free replacement if there are quality issues (damage caused by human factors, overload use, etc. are not within the warranty scope); Only material fees will be charged beyond the warranty period. Accessories and gifts are not covered by the warranty. Q9. How to deliver? Answer: For your convenience, we can send goods through DHL, TNT, UPS, SF, EMS, etc. for prepaid shipping, or use your own courier account to collect shipping fees. Q10. Can I take the sample? Answer: You can contact us to help you get the samples as soon as possible.

    Purchase guide To recommend you the most suitable sensor, please tell us below information. 1. Working temperature: -40~+125 °C ? 2. Test range? 3. Output: 4-20mA , RS485 or others? 4. Screw: G1/4, 1/4NPT, R1/4, M20*1.5? 5. Electrical connection: DIN43650, Packard, Direct lead? 6. Order quantity: ?
