Manufacturers sell MC brand swimming pool pressure gauge Y60 series
Product attribute
1. Model: vacuum pressure gauge
2. Type: vacuum pressure gauge
3. Measurement range
0~40 (MPa)
4. Accuracy level: 1.6
5. Connection type: m14*1.5
6. Nominal diameter: 60 (mm)
7. Ambient temperature
-5~55 (℃)
8. Specifications (detection range and shipping weight)
0~0.1MPa (1kg) 0~0.16MPa (1.6 kg) 0~0.25MPa (2.5 kg) 0~0.4MPa (4kg)
0~0.6MPa (6kg)
0~1MPa (10kg) 0~1.6MPa (16 kg) 0~2.5MPa (25 kg) 0~4MPa (40kg)
0~6MPa (60kg)
0~10MPa (100kg) 0~16MPa (160 kg) 0~25MPa (250 kg) 0~40MPa (400kg)
Product information
| Model number | Y-60 | Type | Radial direction | Shell | Nickel-plated iron |
| Dial diameter | 60mm | Relative humidity | ≤85% | Movement material | Orichalcum |
| Precision | Level 2.5 | Service temperature | - 40 ~ 70 ℃ | Interface material | Orichalcum |
| Measuring range | 0-60MPa | Thread size | M14 * 1.5 | Weight | Radial 140g |
Temperature effect
When the operating temperature deviates from 20 ° C ±50 ° C, it is
not more than 0.4%/10 ° C
Scope of use
General pressure gauges are suitable for measuring the pressure of
liquids, vapors and gases that are not corrosive to copper and
copper alloys without explosion risk, crystallization,
solidification and corrosion
Product size
Other attributes
Customized support
OEM, ODM
Model Number
Y50/Y60/YN60/YTN60 series
Pressure
Mpa,other scale units bar, psi, kg/cm2 etc.optional
Pressure range
-0.1~100mPa
Case material
304/316stainless steel
Working environment
-20~+70°C
