    Keysight Agilent E4408B ESA-L Basic Spectrum Analyzer 9 kHz to 26.5 GHz

    Ask Lasest Price
    Brand Name : Keysight/Agilent
    Model Number : E4408B
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : in stock
    • Product Details
    • Company Profile

    Keysight Agilent E4408B ESA-L Basic Spectrum Analyzer 9 kHz to 26.5 GHz

    Keysight Agilent E4408B ESA-L Basic Spectrum Analyzer 9 kHz to 26.5 GHz

    Description of Keysight Agilent E4408B

    The Agilent Spectrum Analyzer E4408B (9kHz-26.5Ghz)) is an easy-to-use offering a wide range of performance and optional capability to meet your measurements. We have various units available with extended options. Please feel free to inquire for more information.

    If you are looking for a general purpose spectrum analyzer, you will appreciate the flexibility of the Agilent ESA-E Series spectrum analyzer, which can be used for a wide range of applications from aerospace and defense to the manufacturing line. With express analyzer configurations (STD/STG/COM), customers will benefit from faster delivery and its price advantage.

    Performance

    • Testing from L-band Frequencies
    • 4 dB overall amplitude accuracy
    • -167 dBm DANL, with internal preamp

    Measurement applications

    • Phase Noise, Noise Figure, GSM/EDGE, cdmaOne and more
    • PowerSuite one-button power measurements included as standard

    Features:


    • 1.1 dB overall amplitude accuracy, 100 Hz to 5 MHz RBW, 100 Hz to 300 Hz optional, and +7.5 dBm TOI
    • Narrow resolution bandwidth, 8590 series code compatibility, or 50 ohm tracking generator
    • PowerSuite one-button power measurements
    • Rugged, weather resistant design and a snap-on battery pack
    List of Options
    042Gray spectrum analyzer backpack
    044Yellow spectrum analyzer backpack
    049Color Display Upgrade
    0B0Do not include manuals
    0B1Add Manual Set
    0BVService Documentation, Component Level
    0BWService Documentation, Assembly Level
    1A7ESA Series ISO 17025 compliant calibration with test data
    1AXRS-232 and Centronics interface
    1CPRackmount and handle kit
    1D5High stability frequency reference
    1D750 -75 ohm minimum loss pad(s)
    1DN50 Ohm Tracking generator
    1DP75 Ohm input impedance
    1DRNarrow Resolution Bandwidths
    230BenchLink web remote control software
    290859x programming code compatibilty
    521No color display
    A4HGPIB and Centronics interface
    A4JIF and sweep ports
    A5D12 Vdc power cable
    A6JESA Series ANSI Z540 compliant calibration with test data
    AB0Taiwan Quick Users Guide (Chinese localization)
    AB1Korea Quick Users Guide (Korean localization)
    AB2China Quick Users Guide (Chinese localization)
    ABDGermany Quick Users Guide (German localization)
    ABESpain Quick Users Guide (Spanish localization)
    ABFFrance Quick Users Guide (French localization)
    ABJJapan Quick Users Guide (Japanese localization)
    ABZItaly Quick Users Guide (Italian localization)
    AKTRussia - Russian localization (includes English manual set)
    AXTAdd transit case
    AYTGray soft carrying/operating case
    AYUYellow soft carrying/operating case
    B70BenchLink spectrum analyzer S/W
    B72Increase memory to 16MB
    BABAPC 3.5 Input Connector
    BASBasic analyzer (A4J)
    BTGBasic analyzer with tracking generator (1DN, A4J)
    R-50C-011-3Agilent Calibration - 3 years
    R-50C-011-5Agilent Calibration - 5 years
    R-50C-016-3ISO 17025 Compliant Calibration - 3 years
    R-50C-016-5ISO 17025 Compliant Calibration - 5 years
    R-50C-021-3ANSI Z540-1-1994 Calibration - 3 years
    R-50C-021-5ANSI Z540-1-1994 Calibration - 5 years
    R-51B-001-3CReturn to Agilent Warranty - 3 years
    R-51B-001-5CReturn to Agilent Warranty - 5 years
    R-51B-001-CReturn to Agilent Warranty - 1 year
    RMKTAgilent Refurbished Product (Do Not Use - Certiprime Option)
    UK6Commercial cal. Certificate w/test data
    UK9Front panel cover

    FAQ:

    1.Can you ship order to Canada or Australia ?

    Yes,we can .We send orders worldwide .

    2. What delivery method do you use ? and delivery time ?

    We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual delivery time is 4-7 workdays.

    3. What is your payment term?

    100% T/T payment before shipment.

    4. How can I ask any other question ?

    You can contact us online or leave us messages below .
