    Mcu 37 Pin 2.8 Inch Touch Screen Lcd Display Module With Resistance Touch

    Ask Lasest Price
    Brand Name : Polcd
    Model Number : P028C105-7789
    Certification : RoHS, ISO9001
    Price : Please contact us for latest price
    Payment Terms : T/T, L/C, Credit card, PayPal, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 25,000 PCS per day
    Delivery Time : 1-7 working days
    • Product Details
    • Company Profile

    Mcu 37 Pin 2.8 Inch Touch Screen Lcd Display Module With Resistance Touch

    Description of 2.8 inch IPS TFT LCD :

    2.8 inch TN LCD modules offer a reliable and cost-effective display solution for various applications, providing a compact and low-power display option. However, their limited viewing angle and color depth may make them less suitable for applications that require high-quality color reproduction or wide viewing angles.


    Parameter:

    ModelP028C105-7789
    Screen Size2.8 inch
    Number of Pixel240RGB(H)x320(V)
    Display area43.20(H)x57.60(V)mm
    Pixel pitch0.06(H)x0.18(V)mm
    Pins40 pins
    Outline Dimension50.00x69.20x2.3mm
    Pixel arrangementRGB Vertical Stripe
    Display modeNormally White
    Viewing Direction(eye)12 0'CLOCK or IPS
    Display Color262K
    Luminance(cd/m2)300 nit
    Contrast Ratio500:1
    InterfaceMCU 8/16bit SPI 3wire/4wire
    Back-lightLED Side-light type
    Drive ICST7789V
    Operation Temperature-20~70℃
    Storage Temperature-30~80℃

    There are several advantages of using 2.8 inch TN (Twisted Nematic) LCD modules in portable electronic devices, including:


    1.Compact Size: 2.8 inch TN LCD modules are relatively small in size, making them an ideal choice for portable electronic devices. They can easily fit into handheld devices and other small form factor devices without taking up too much space.

    2.Low Power Consumption: TN LCD modules are known for their low power consumption, making them a great choice for portable electronic devices that rely on battery power. They can help extend the battery life of the device, allowing users to use the device for longer periods of time without needing to recharge.

    3.Cost-Effective: TN LCD modules are generally less expensive than other types of display technologies, such as OLED or IPS displays. This makes them a popular choice for manufacturers of portable electronic devices who are looking for a cost-effective display solution.

    4.Good Contrast: TN LCD modules have a good contrast ratio, which means that they can display clear and sharp images with good contrast between light and dark areas. This is important for portable electronic devices that need to display clear and readable text and graphics.

    5.Easy to Read in Bright Light: TN LCD modules have a reflective layer that makes them easier to read in bright light conditions, such as outdoors in sunlight. This is important for portable electronic devices that may be used in a variety of lighting conditions.
