    Multi Function Vertical Front Operation Intelligent SMT Production Line Automatic 90 Degree PCB Turn Conveyor

    Ask Lasest Price
    Brand Name : HSTECH
    Model Number : HS-ZJ350
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 100 sets per month
    Delivery Time : 7~9 work days
    • Product Details
    • Company Profile

    Multi Function Vertical Front Operation Intelligent SMT Production Line Automatic 90 Degree PCB Turn Conveyor


    Multi Function Vertical Front Operation Intelligent SMT Production Line Automatic 90 Degree PCB Turn Conveyor


    Technical Details

    FunctionThis unit is used for redirect the PCBs flow direction on production line(90degree,180degree,or 270degree)
    Transport height910±20mm
    Transportation directionL~R, or R~L
    Cycle timeApprox 5 seconds
    Track fixed sideFront side
    Power supplyAC100-230V,50/60Hz,single phase
    Air pressure4-6bar
    Air consumptionMax 10L/min
    PCB thicknessMin 0.4mm
    SignalSMEMA

    Specification

    ModelHS-ZJ350HS-ZJ500
    Efficient PCB length50*50~500*350mm50*50~500*500mm
    Machine dimension700*750*1200mm840*890*1200mm
    Weight150kg180kg

    Features

    1, Enclosed design with built-in torque limiter ensure high level of safety.

    2, Top safe cover can be opened for each access to hardware during Maintenance.

    3, Use friendly control button.

    4, Smooth and precise rotation.

    5, Minimize the transfer gap between conveyors.

    6, PCB traffic flows can be customized.

    7, Smooth and parallel width adjustment(lead screw).

    8,SMEMA compatible.


    Machine drawing

    Application

    This unit is used for redirect the PCBs flow direction on production line(90degree,180degree,or 270degree)


    About Packaging
