Specifications:
DCV 90 day ±1°C specifications to 1 + 0.15 ppm.
Calibrate DMMs up to 8.5 digits
ACV, DCV, AVI, DCI & Ohms (with options)
1kV AC output
GPIB interface
Used either as a component in an automated calibration system or as
a standalone bench instrument, the Datron range of Multifunction
calibrators offers the most cost effective solution to today's
calibration problems. Initial purchase costs are reduced by the
inclusion of a full capability 1000V DC and AC power amplifier in
the calibrator chassis, enabling a single unit to cover the widest
possible calibration workload
List of Options
010 DC Voltage function to +/- 200V
020 AC Voltage to 200V
030 Integeral 1000V amplifier for AC/DC (Requires option 10, 20, or
both)
040 Current Converter (DC Current requires opt 010, AC Current
requires opt 020)
050 Resistance function (Requires opt 10 or 20)
060 Current Range extension to 11Amps. (Includes Datron 4600 and
all necessary cables)
070 Wide-band to 3.5V/30 Mhz. Increases Height by 1U. Output is
type N (f) connector. (requires opt 020)
080 115 VAC 60Hz line operation.
081 115 VAC 50Hz line operation.
082 115 VAC 400Hz line operation.
090 Rack Mount Kit. (Std 19 IN)
FAQ:
1.Can you ship order to Canada or Australia ?
Yes,we can .We send orders worldwide .
2. What delivery method do you use ? and delivery time ?
We can ship by EMS,DHL,FedEx,UPS,TNT with tracking number. Usual
delivery time is 4-7 workdays.
3. What is your payment term?
100% T/T payment before shipment.
4. How can I ask any other question ?
You can contact us online or leave us messages below .
