CH6250 universal lathe machine tool

    Buy cheap CH6250 universal lathe machine tool from wholesalers

    Buy cheap CH6250 universal lathe machine tool from wholesalers
    • Buy cheap CH6250 universal lathe machine tool from wholesalers

    CH6250 universal lathe machine tool

    Ask Lasest Price
    Brand Name : Sumore
    Certification : CE
    Model Number : CH6250
    • Product Details
    • Company Profile

    CH6250 universal lathe machine tool

    CH6250 universal lathe machine tool


    Specifications


    capacity

    swing over bed 500mm
    swing over cross slide 325mm
    swing over gap 630mm
    length of gap 260mm
    center distance 1000/1500/2000mm
    width of bed 330mm


    carriage

    tool shank size 25X25mm
    cross slide travel 300mm
    compound rest travel 130mm


    headstock

    spindle bore 65mm
    spindle nose ISO-C6 or D6
    spindle taper metric 70mm
    spindle speed 22-1800rpm


    tailstock

    tailstock sleeve 65mm

    tailstock taper MT5

    tailstock travel 120mm


    motor

    main motor power 5.5KW/7.5KW

    coolant pump power 125W


    standard accessories

    3 jaw chuck,4 jaw chuck,steady rest,follow rest,face plate,working lamp,coolant system


    Company Information

    As you can see from Alibaba ,we have been in this field for over 10 year .Now we supply a wide range of lathe, mill , drill , CNC and other tools for hobby and industrial market with different specifications and prices for your choice.If any need , please contact us dirctly at shenlong at sumore.com via mail.


    FAQ

    All the parameters are for reference .We reserve the rights to change before further notice .Anything , please consult our sales department.


    Contact us

    Please don't hesitate to write to us via shenlong@sumore.com

    Phone number 86-21-61478329 , Monday to Friday , 9:00 - 17:00
