1, This Linsn TS802 sending card need to work with Linsn RV901 or
RV908 receiving card.
2, Customer need to buy the Hub75 Transfer Board.
3, Used in the synchronous controller system
Mark
TS802 is upgraded version of sending card TS801. Factory has stopped to produce TS801.
Compared with TS801 card, TS802 has following features:
1. Display More Colors
TS801 can display 256X256X256=1677216 colors
TS802 can display 1024X1024X1024=1073741824 colors
64 times
TS802 will make your LED display more vivid,more active,more
colorful
2.Smart Control Functions
With receiving cards,one TS802 sending card can control several LED
displays.
User can change positions of these LED displays at will and no need
to set up the software one more time. Receiving cards can check
needed display informations automatically.
And,different LED displays can play synchronously or independently.
3.Display Company Logo When Power On
After user input his company logo at first,the LED display will
show this logo when power on next time and later on.
Logo size is 128x128 pixels.
4.Support More Scan Modes
Scan modes that TS801 can support are: static,1/2,1/4,1/8,1/16
TS802 can support scan modes are: static,
1/2,1/3,1/4,1/5,1/6,1/7,1/8,1/9,1/10,1/11,1/12,1/13,1/14,1/15,1/16
So,TS802 can be used for more scan modes of LED displays.
5.Support Abnormal Shape of LED Dispays,Divided Text Display
One receiving card supports 1024 parts of divided informations in
max.
6.65536 Grade (64K) adjustable Gray Scale
Users can adjust the gray scale by themselves from 0 to 65536 grade
to get the best display effect.
6.Wide Range of Refresh Rate
Users can choose the refresh rate from 10Hz-3000Hz,make sure the
vodeo / image complete,definitely.
7.Back Up Function
Users can use 2 different computers to control the same one LED
display.
If one computer have problems,another computer will work
automatically.
Users can also use 2 pieces of RJ45 cable to control the same one
LED display.
If one RJ45 cable have problems,another computer will work
automatically.
This function will make sure the LED display work smoothly.
8.256 Grade of Brightness Adjustment
9.Online Update Function
If the software for receiving cards needs to be updated,just turn
on the LED display and update the software online,no need to take
off the receiving cards from the LED display.
