    WCDMA / GSM / GPRS 4G LTE Module MC7355 Low Cost RF Modules 433mhz

    Ask Lasest Price
    Brand Name : SIERRA WIRELESS
    Model Number : MC7355
    Certification : CE, GCF, Telstra
    Price : 90$~95$/pcs
    Payment Terms : T/T, paypal or western Union
    Supply Ability : 3,000pcs per month
    Delivery Time : 2-3 working days after received the payment
    • Product Details
    • Company Profile

    WCDMA / GSM / GPRS 4G LTE Module MC7355 Low Cost RF Modules 433mhz

    WCDMA / GSM / GPRS 4G LTE Module MC7355 Low Cost RF Modules 433mhz


    The Sierra Wireless MC7355 PCI Express Mini Card is a compact,

    lightweight, wireless LTE-, UMTS-, and CDMA-based modem.

    The MC7355 provides LTE, DC-HSPA+, HSPA+, HSDPA, HSUPA,

    WCDMA, GSM, GPRS, EDGE, CDMA, and GNSS connectivity for

    notebook, ultrabook, and tablet computers over several radio

    frequency bands. The device also supports 2G/3G roaming.


    Supported RF bands


    The modem, based on Qualcomm's MDM9615 baseband processor,

    supports data operation on LTE, DC-HSPA+, HSPA+, EDGE, GPRS,

    GSM, and CDMA networks.


    Supported RF bands

    Technology

    Bands

    Notes

    Data rates

    LTE

    • Band 2 (1900 MHz)

    MIMO support

    · Downlink:

    • Band 4(AWS)(1700/2100MHz)

    100 Mbps (20 MHz bandwidth)

    • Band 5 (850 MHz)

    50 Mbps (10 MHz bandwidth)

    • Band 13 (700 MHz)

    · Uplink:

    • Band 17 (700 MHz)

    50 Mbps (20 MHz bandwidth)

    • Band 25 (1900 MHz G Block)

    25 Mbps (10 MHz bandwidth)

    CDMA EVDO Release 0 and EVDO Release A

    • BC0 (Cellular 800 MHz)

    Diversity support

    CDMA IS-856 (1xEV-DO Release A)

    · Up to 3.1 Mbps forward channel

    • BC1 (PCS 1900 MHz)

    · Up to 1.8 Mbps reverse channel

    CDMA IS-2000

    · Up to 153 kbps, simultaneous

    • BC10 (Secondary 800 MHz)

    forward and reverse channel

    Circuit-switched data bearers

    up to14.4 kbps

    UMTS (WCDMA)

    • Band 1 (2100 MHz)

    Diversity support

    HSPA+ rates

    HSDPA

    • Band 2 (1900 MHz)

    · Downlink: Up to 42 Mbps

    HSUPA

    • Band 4 (AWS 1700/2100MHz)

    (category 24)

    HSPA+

    • Band 5 (850 MHz)

    · Uplink: Up to 5.76 Mbps

    DC-HSPA+

    • Band 8 (900 MHz)

    (category 6)


    Short Message Service (SMS) features

    Mobile-terminated SMS for CDMA and UMTS

    Mobile-originated SMS for CDMA and UMTS

    SMS over SGs (LTE)

    Mobile-terminated SMS over IMS for LTE/eHRPD

    Mobile-terminated SMS over GPRS/UMTS/HSPA/HRPD/1xRTT


    Position location (GNSS)

    • Concurrent standalone GPS and GLONASS

    • Assisted GPS (A-GPS) SUPL1.0

    • Assisted GNSS (A-GNSS) SUPL2.0

    • gpsOneXTRA 2.0 with GPS + GLONASS support

    • GNSS on dedicated connector or diversity connector


    Warranty and support

    The MC7355 offers the following support features:

    • Standard 1-year warranty

    • Enabling software (drivers, SDK, etc.) for Android RIL (Radio Interface Layer)

    v4.0 (Ice Cream Sandwich) and later, Linux, Windows 7, and Windows 8


    Supporting documents

    Any datasheet and Technical Support, pls contact us any time via sales at topelecind.com


    Application:

    The device is designed to be network operator-certified. Contact

    Us for details.

    Packing:
